Husqvarna 967277601 warranty Place controls in neutral position Full throttle position

Page 29

OPERATION

5.Move the steering controls outward to the locked (outer) neutral position.

6.Move the throttle lever to the full throttle position. NOTE: There is a detent at the full throttle position to aid in setting the control.

If the temperature is below 32OF, move the throttle lever up to the cold weather (snowflake) starting position.

When the engine has started, move the throttle lever back to full throttle detent and allow the engine to warm up for a short period before operating the unit. Failure to move the throttle from the cold weather starting position will result in poor engine performance, smoke and spark plug fouling.

8058-190

Place controls in neutral position

8058-248

Full throttle position

29

Image 29
Contents Operator Manual All rights reserved Contents Page Introduction Manufacturing Number Good ServiceXxxx xxxxxx xxxxx xxxx Xxxxxx xxxxxxxxx. xx xxxxxxxx Symbols and DecalsShut off engine before Performing any General Operation SafetySafety Instructions Never take passengers Slope Operation Personal Safety EquipmentChildren Safe Handling of Gasoline General Maintenance Risk of sparking Safety System Spark Arrestor TransportControl Locations ControlsSteering Control Levers Cold Weather Control Park BrakeThrottle Control SmartSwitch Courtesy Buttons Blade SwitchIgnition Switch Seat Adjustment Lever Service MinderSeat should not be adjusted while unit is in motion Tracking KnobFuel Tank FuseFuel Shut Off Valve Cutting Height AdjusterBypass Linkages Always raise the deck to the highest position for transportSteering OperationTraining Resetting ignition system passcode SmartSwitch IgnitionBefore Starting Starting the Engine Place controls in neutral position Full throttle position Important Information Ignition System Faults Running Stopping the Engine Operating On Hills Mowing Tips Headlights Weak BatteryJumper Cables Use To remove cables, reverse orderMoving Machine By Hand Battery Voltage LightChecking Battery Charge System Maintenance Schedule MaintenanceBefore After Year Replacing battery BatterySteering controls locked in neutral Tire Pressures Removal and installation of caster wheelAnti-scalp Rollers Caster WheelsDeck Belt Removal Deck Belt InstallationBelts Cutting Blades Leveling deck Adjusting the Mower DeckHardware CleaningUse protective glasses when cleaning and washing General LubricationLubrication Schedule Transmission Wheel and Deck ZerksFront Wheel Mount Front Wheel BearingsProblem Cause TroubleshootingTroubleshooting Winter Storage ServiceStorage Schematic Torque Specifications Technical DataAccessories Standard HardwareEngine DimensionsTransmission FrameUSA requirements Conformity CertificatesDelivery Service Service JournalAfter the First 10 Hours Hour ServicePerform the 25-hour service At Least Once Each Year Service Journal Service Journal Service Journal Page 115 646927 Rev a 2013-10-15

967277601 specifications

The Husqvarna 967277601 is a high-performance chainsaw designed for both professional and avid homeowners who require reliable tools for their outdoor projects. This model stands out due to its powerful engine, advanced features, and ergonomic design, making it suitable for a range of cutting tasks, from felling trees to pruning branches.

One of the primary attributes of the Husqvarna 967277601 is its potent engine. Equipped with a robust two-stroke engine, this chainsaw delivers impressive horsepower, facilitating efficient cutting and reducing the risk of bogging down even in dense wood. The air injection technology enhances the engine's performance by utilizing centrifugal force to remove larger debris particles from the air intake before they reach the air filter. This feature not only prolongs the life of the air filter but also improves fuel efficiency and reduces emissions.

The chainsaw incorporates a lightweight yet durable design that makes it easy to maneuver during operation. The design embraces components constructed from high-quality materials, ensuring both resilience and comfort. A comfortable grip is essential for extended use, and Husqvarna recognizes this need. The anti-vibration system significantly reduces the impact of vibrations on the operator’s hands, allowing for longer working periods without fatigue.

Husqvarna 967277601 features a user-friendly starting system. The Smart Start technology allows for easy starting with minimal effort, which is especially beneficial when working in demanding conditions. The chainsaw also includes an adjustable oil pump that enhances chain lubrication while conserving oil as needed. This ensures optimal performance and longevity of the cutting system while maintaining environmentally responsible practices.

In terms of safety, the model is equipped with features such as a chain brake, which activates automatically when a sudden kickback occurs, protecting the user from injury. The easily accessible controls enhance safety as well, allowing operators to manage the saw’s functions safely.

Overall, the Husqvarna 967277601 chainsaw embodies a perfect synergy of power, innovative technology, and user-friendly features, positioning it as an ideal choice for individuals seeking efficiency and reliability in their cutting tools. Whether for heavy-duty tasks or light garden maintenance, this chainsaw meets a variety of needs while ensuring operator comfort and safety.
