2 FMM‑462 Series POPIT Addressable Manual Stations
Installation/Configuration Notes
Compatibility Information
The FMM‑462 Series Addressable Manual Stations are compatible with the following products:
Category | Product ID | Product Description |
Control | D7212G | Control panel |
Panels: | D7412G | Control panel |
| D9412G | Control panel |
| D9124 | Addressable FACP |
Modules | D9127U | POPIT module |
Mounting Considerations
The FMM‑462 manual stations are for indoor use only. The FMM‑462 or FMM‑462‑D and the wiring from the control panel data expansion loop fit into a
Parts Included
Quant. Component
1Manual station
1D9127U POPIT module
1FMM‑100GR scored acrylic breakrod
1D102 Key (1358)
1Literature pack
Technical Specifications
Environmental Considerations
Temperature (operating): |
| +14°F to +120°F |
|
|
|
Mechanical Properties | ||
|
| |
Activation Force: | 5 lb (2.3 kg) | |
|
| |
Alarm Response Time: | 1 sec (approximately) | |
|
| |
Dimensions (HxWxD): | 4.75 in. x 3.2 in. x 0.875 in. | |
| (12.1 cm x 8.1 cm x 2.2 cm) | |
Material: | Painted die‑cast metal, plated steel back | |
| and painted steel front | |
Power Requirements | ||
|
| |
Current (alarm): | 0.8 mA | |
|
| |
Current (normal): | 0.5 mA | |
|
| |
Voltage (operating): | 7 VDC to 15 VDC supplied by the control | |
| panel | |
|
|
|
Ordering Information
FMM‑462 Single‑Action Manual Station
A
Order number
FMM‑462‑D Double‑Action Manual Station
A
Order number
Accessories
D102 Replacement Key
Replacement key (#1358) for the D101 lock.
Order number D102
FMM‑100BB‑R Surface‑mount Back Box (red)
Red cast‑metal back box
Order number
FMM‑100GR Scored Acrylic Break Rods
Scored acrylic rods (12 per package)
Order number
