Cub Cadet 6031 Commercial Zero-Turn Riders, Attachments, collection system with, triple bagger

ATTACHMENTS

COMMERCIAL ZERO-TURN RIDERS

ENGINE TANK™ S 6031 TANK™ S 7237

THAT BOOST PRODUCTIVITY ALL YEAR ROUND

Whether you’re working through the heat of summer or the dead of winter, our attachments are made to boost your earning potential the whole year through. So you can maximize your profits while getting the best results possible.

collection system with

Engine type

Engine displacement/orientation Engine fuel

Ignition Lubrication/filter Cooling system Air cleaner Alternator Fuel capacity

31 HP* Kawasaki® V-Twin OHV	37 HP* Kawasaki® V-Twin OHV
852cc/vertical	999cc/vertical

Gas

Capacitor discharge ignition (CDI)

Full pressure w/spin-on oil filter

Air

Heavy-duty remote — replaceable dual element

12V – 15 amp. regulated

Twin 7-gal. tanks w/fuel gauge

POWER ASSIST DUMP HOPPER

DRIVE SYSTEM

Fits 60" deck only.

triple bagger

Fits 60" deck only.

Drive system Ground speed Hydraulic fluid Hydro fluid capacity Hydraulic oil filter Controls

Lock to lock turns (steering wheel) Braking/parking brake

Dual Hydro-Gear™ PK-12 pumps & 310cc Parker wheel motors

Fwd: 10 mph/Rev: 5 mph

Shell Rimula® — 15W40 and remote cooling system

6 qt.

Standard, 25-micron cartridge type

Individual forward, reverse and park brake foot pedals 2 turns /multi-position steering wheel and column Expansion shoe/drum

ULTRA- TRACTION TIRES

12-VOLT OUTLET

FUEL

GAUGE

STEERING

Power steering (front wheels)	Fully hydraulic power steering w/Synchro Steer™ technology
Front axle				Pivoting, cast-iron axle
CHASSIS
Frame	Fully welded 2", heavy-duty tubular steel (wide-track)
Tires
Front tire size		16" x 6.5" – 8" (Turf Trac R/S)
Rear tire size			24" x 12" – 12" (Turf Master®)
Dimensions
Length x width x height	89" x 62" x 72"							89" x 74" x 72"
Wheelbase							54"
Front tread width					49.5"
Rear tread width						58"
Weight (approx.)	1,470 lbs.							1,540 lbs.

Mowing deck

fully enclosed cab

SPREADER

mulch kit

Safety shield and toe guard must remain installed after mulch kit is added.

Deck size/type

Deck style/system

Deck blades

Deck construction

Deck wash

Deck lift

Deck height adjustment

Blade spindle construction

PTO engagement

Front anti-scalping wheels

Rear anti-scalping rollers/striper

Deck PTO

Additional Specifications

60" Select Cut System™		72" Select Cut System™
	6-point suspension, full floating
Three 21," high lift with		Three 25," med. lift with
extended cutting edge		extended cutting edge

10-gauge fabricated with 7-gauge steel skirt, 3/8" rub guard, 1/4" adjustable leading edge and 7- and 10-gauge reinforcements at spindle assemblies

Patented SmartJet™ high-pressure deck washing system

Dash-mount control lever w/hydraulic lift system

1" – 5" (in .25" increments)

Durable machined cast-aluminum housing

w/greasable tapered roller bearings

Ogura GT 3.5/250 ft. lb.

4 standard, greasable		4 standard, greasable
Full-width adjustable striper		Full-width adjustable striper/
		2 corner rollers
	Electronic fingertip engagement

LIGHT KIT

SNOW

BLADE

ROPS			Foldable (OSHA-1928 compliant)
Monitor/hour meter	Standard, hour/tachometer/maintenance minder
Seat type/motion range front/rear	Fully adjustable suspension, lumbar and armrests
		and reclining back w/8.25" of travel
Cup holder	Accommodates multiple-size containers
Storage pouch					Standard
Bumper & rear hitch	Heavy-duty bumper w/rear hitch standard
WARRANTY†
				3-year limited commercial

*as rated by engine manufacturer

†See your local Cub Cadet Independent Commercial Dealer for warranty details. Commercial products are intended for professional use.
