D1 Spas Series – General Specifications – 2004 Chairman
General | Domestic (60Hz) | Part # | Export (50Hz) | Part # | |
Shape | Square |
| Square |
| |
Shell Material | Ultralife™ / Granitex™ |
| Ultralife™ / Granitex™ |
| |
Height | 35 ½ in. |
| 90 cm |
| |
Width | 91 ½ in. |
| 232 cm |
| |
Length | 91 ½ in. |
| 232 cm |
| |
Corner Radii | 16 in. |
| 41 cm |
| |
Seating Capacity | 6 |
| 6 |
| |
Water Capacity | 400 Gallons |
| 1514 Liters |
| |
Dry Weight | 685 lbs |
| 311 kg |
| |
Full Weight | 4017 lbs |
| 1822 kg |
| |
Skirt Material | Wood or Synthetic |
| Wood or Synthetic |
| |
Poly Floor | Yes |
| Yes |
| |
Water System |
|
|
|
| |
Pump Brand | HydraMax by |
|
| ||
Motor Size | 4.0 HP |
| 2.0 HP |
| |
# Pumps/Speed | Two / Dual | Two / single | |||
Plumbing Systems | 4 |
| 4 |
| |
Pump Returns | 4 | 4 | |||
Typhoon Jets | 1 | 1 | |||
VCR Jet® - Air | 9 | 9 | |||
Adjustable/Directional | |||||
|
|
|
| ||
VCR Jet® - Rotator | 13 | 13 | |||
VCR Jet® - Mini Rotator | 2 | 2 | |||
VCR Jet® - Mini Directional | 6 | 6 | |||
VCR Jet® - Mini Directional in NFJ | 8 | 8 | |||
VCR Jet® - Euro Directional | 0 |
| 0 |
| |
Ozone Jet | 1 | 1 | |||
Heater Return Jet | 1 | 1 | |||
Total Jets | 41 |
| 41 |
| |
Filters/Coverage | 2 / 75 sq. ft. | (2) | 2 / 6.97 sq. meters | (2) | |
Water Treatment System | Ultra Pure™ |
| Ultra Pure™ |
| |
Gate Valves | 4 | 4 | |||
Diverter Valves | 2 | 2 | |||
Floor Drains | 1 | 1 | |||
Skimmer | 8” Weir | 20 cm Weir | |||
Electrical System |
|
|
|
| |
Voltage | 240 |
| 240 |
| |
Amperage | 50/40/30 |
| 1X16 / 2X16 / 1X32 |
| |
Heater | FastFlo 2.7,4.0,5.5 kW | FastFlo 2.9 kW | |||
Thermostat | Electronic |
| Electronic |
| |
Light | 1 with optional LED | 1 with optional LED | |||
Control System |
| ||||
Upper Control | Scrolling Message Center | Scrolling Message Center | |||
Auxiliary Upper Control | Yes |
| Yes |
| |
Programmable | Yes |
| Yes |
| |
Special Features |
|
|
|
| |
Dynamic Massage Sequencer w/ | No |
| No |
| |
control panel |
|
| |||
|
|
|
| ||
NeckFlex® Jet Pillows | 2 | 2 | |||
Headrest Pillows | 1 | 1 | |||
Cup Holders | 3 |
| 3 |
| |
Tactile Therapy | Foot & hand |
| Foot & hand |
| |
|
|
|
|
|
Note: Subject to change without notice. |
|
|
| 2004, Chairman | Page 1 of 5 |
