The technology inside

ECLIPSE managed to fit all the technology to handle navigation and entertainment into a one-DIN enclosure without compromising performance.

20GB 1.8˝ HDD

Using 1.8˝ HDD instead of a 2.5˝ HDD helped maintain the compact, ultra-efficient design, taking up 30% less valuable real estate.

Space-saving construction techniques

Circuit board construction utilizes advanced modules comprised of DAC, memory and flash memory integrated circuits that make it possible to downsize the circuit boards, which in turn help achieve the ultra space-efficient one-DIN unit configuration of the AVN7000.

Ultima Engine

MS Duo Slot

Detachable Front Panel

Proximity layout

Important circuit components such as the DAC and MOSFET devices are closely positioned next to the output terminals for the most effective signal transmission and to cancel any potential noise pickup. This adds up to delivering better audio performance.

DAC MOSFETs OUTPUT

The culminating effect of all these efforts allows the AVN7000 to be free from noise and provide a performance that impresses.

Sub display

7˝ wide TFT display

Design accents

Chrome and silver style highlights

Brilliant mirror coating



The stylish silver strip accents the pushbuttons

Adding a style-conscious design accent is a

on the side while the control knob and other

special mirror finish that allows the unit’s

buttons are finished in chrome for an elegant

precision-cut edges to attractively refract light

touch of contrast with the piano-black finish of

in brilliant colors.





the unit.

Dual color illumination









To suit user preferences







and car interiors, the







switches offer a choice







of color illumination.

BLUE

RED

Ultima Engine

This computing engine combines navigation and graphics processing integrated chips in one monolithic configuration for accelerated data processing.

Over 32,000 map colors

Screen translucency

On-screen information now “floats” above a map display so it’s easier to see and less distracting.

Antialiasing

The Ultima Navigation Engine allows many more colors to be simultaneously used without “jaggies” and greater resolution.
