HP CP6015n, CP6015xh manual Technical specifications, Professional Results Every Time

Technical specifications

Print technology

Print speed

Processor

Memory

Print resolution

Print quality Printer languages Typefaces/fonts

Duty cycle (monthly, A4) Recommended Monthly Page Volume Print margins

Media handling

Media types

Interface and connectivity

Network Capabilities Operating systems compatibility

Network operating systems compatibility

Minimum system requirements

Software

Control panel

Printer management

Upgradability

Power

Dimensions (w x d x h)

Weight

Operating environment

Product certifications

Warranty

In-line colour laser printing technology

A4 black: Up to 41 ppm, colour: Up to 41 ppm

First page out Black: < 11 sec (from "ready"), colour: < 11.5 sec (from "ready")

Exact speed varies depending on the system configuration, software application, driver, and document complexity 835 MHz, PMC Processor

512 MB

Black: Up to 1200 x 600 dpi

Colour: Up to 1200 x 600 dpi HP ImageREt 4800

HP PCL 6, HP PCL 5, HP Postscript level 3 emulation, native PDF printing (v1.3)

93 HP fonts (plus Greek, Hebrew, Cyrillic, Arabic) Up to 175000 pages

4000 to 17000

top: 2 mm, left: 2 mm, right: 2 mm, bottom: 2 mm

Input	Capacity	Weight	Size
Tray 1	sheets: 100, colour transparencies: 50,	60 to 220 g/m²	A3, A4, A4-R, A5, envelope (No. 10, DL, C5,
	envelopes: 10		B5, Monarch), B4 (JIS), B5 (JIS), executive (JIS),
			double postcard (JIS), A6, B6, 99 x 140 mm to
			320 x 457 mm, Banner: 99 to 320 mm x up to
			915 mm
Tray 2	sheets: 500	60 to 220 g/m²	A3, A4, A5, B4 (JIS), B5 (JIS), 148 x 210 mm to
			297 x 432 mm
Duplex printing:	CP6015n: Manual (driver support provided);		A3, A4, A5, A6, B4 (JIS), B5 (JIS), B6 (JIS)
	CP6015dn: Automatic; CP6015xh: Automatic
Output:	Sheets: Up to 500. Envelopes: Up to 10. Transparencies: Up to 500

Paper (extra heavy, glossy, heavy, heavy glossy, high gloss images, intermediate, light, plain, recycle, tough), envelopes, labels, cardstock, transparencies

Two host USB 2.0-like ports for third party connections, Hi-Speed USB device port (compatible with USB 2.0 specifications), two EIO slots, HP Jetdirect Gigabit Ethernet Print server, Jetlink, accessory port for Kensington Lock

Via HP Jetdirect internal Fast Ethernet, Gigabit Ethernet, 802.11b wireless

Microsoft® Windows® 2000, XP Home, XP Professional, Server 2003 (32/64 bit), Server 2008; Windows Vista®; Mac OS X v10.2 or higher

Optional: UNIX drivers are available at http://www.hp.com/go/unixmodelscripts, Linux drivers are available at http://www.hp.com/go/linusprinting, and latest printer information and drivers are available at http://www.hp.com/support/cljcp6015

Microsoft® Windows® 2000, Server 2003, Server 2008, XP, 2003 64-bit, XP 64-bit; Windows Vista®, Windows Vista® 64-bit (For Microsoft® IPv6 compatible with Windows® 2003, XP, and Windows Vista®); Novell® 5.1 and later; Mac OS X v10.2, v10.3, v10.4 and later; RED HAT Linux 7.x and later; SUSE Linux 8.x and later; HP-UX 10.20, 11.x, 11.i; Solaris® 2.5 and later (SPARC® systems only); IBM® AIX 3.2.5 and later; MPE-iX; Citrix® MetaFrame Server; Windows® Terminal Services

Microsoft® Windows® XP (32-bit and 64-bit), Server 2003 (32-bit and 64-bit), 2000 (32-bit and 64-bit), Windows Vista® (32-bit and 64-bit), Mac OS X v10.2 or higher; PowerPC processor or Intel® Core processor

Print drivers and installation software on CD-ROM, HP PCL 6, HP Postscript Level 3 emulation (HP PCL 5c on web only)

LCD control panel display with 4 lines of text and capable of showing graphic animations; 3 status lights; Attention light; Data light; and Ready light. Help (appears as a question mark), Select (appears as a checkmark), Up arrow, Down arrow, Back arrow buttons; Numeric 10-key pad for pin printing and other numeric values

HP Web Jetadmin, HP Embedded Web Server, HP Easy Printer Care

CP6015n: 1 x 500-sheet input tray plus cabinet OR 3 x 500-sheet input tray; high capacity hard drive; memory; CP6015dn: 1 x 500-sheet input tray plus cabinet OR 3 x

500-sheet input tray; high capacity hard drive; memory; CP6015xh: Memory; finishing devices include stapler/stacker and booklet maker

Requirements: Input voltage 100 to 127 VAC (- 10 /+ 10%), 50/60 Hz (+/- 2 Hz); 220 to 240 VAC (- 10 /+ 10%), 50/60 Hz (+/- 2 Hz)

Out of package: CP6015n: 704 x 635 x 580 mm; CP6015dn: 704 x 635 x 580 mm; CP6015xh: 704 x 635 x 972.8 mm

Packaged: CP6015n: 900 x 800 x 860 mm; CP6015dn: 900 x 800 x 860 mm; CP6015xh: 935 x 800 x 1210 mm

Out of package: CP6015n: 86.2 kg; CP6015dn: 86.2 kg; CP6015xh: 119.6 kg

Packaged: CP6015n: 103.20 kg; CP6015dn: 103.20 kg; CP6015xh: 150.85 kg

Operating temperature: 10 to 30° C. Recommended operating temperature: 17 to 25° C. Operating humidity: 10 to 80% RH. Recommended operating humidity: 30 to

70% RH. Storage temperature: 0 to 35° C. Storage humidity: 5 to 95% RH. Noise level per ISO 9296: Sound power: LwAd 6.9 B(A) (printing at 41 ppm), inaudible (ready).

Sound pressure: LpAm 54 dB(A) (active), inaudible (ready)

Safety certifications: Argentina (TÜV S Mark-Rs.92/98/Ds.1009/98), Australia (AS/NZ 3260), Canada (cUL-CAN/CSA C22.2 No.60950-00), China (GB4943), Czech Republic (CSN-IEC 60950-IEC 60825-1), Estonia (EEI-EN60950-IEC 60825-1), EU (CE Mark-Low Voltage Directive 73/23/EEC), Germany (TÜV- EN60950-IEC 60825-1), Hungary (MEEI- IEC 60950-IEC 60825-1), Japan Radio Law, Lithuania (LS- IEC 60950-IEC 60825-1), Mexico (NOM NYCE-NOM 019 SCFI), Poland (B Mark- IEC

60950-IEC60825-1), (Russia (GOST- R50377), Slovakia (IEC 60950-IEC60825-1), Slovenia (SQI- IEC 60950-EN60825-1), South Africa (IEC 60950-IEC60825-1), USA (UL-UL 60950, FDA-21 CFR Chapter 1 Subchapter J for lasers); Class 1 Laser/LED Product

EMC certifications: CISPR 22: 1997/EN 55022: 1998 Class B, EN 61000-3-2:2000, EN 61000-3-3: 1995, EN 55024: 1998, FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 4/GB9254-1998, GB17625.1-2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC, and carries the CE-Marking accordingly

One year on-site

http://www.hp.com/uk

Professional Results Every Time

© Copyright 2008 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP Products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Published in EMEA 09/08 4AA1-7353EEE
