JL Audio SB-GM-SLVCRW/10W1v2 HD Series Only, Series Trucks, go to Step, Drivers sidenot pictured

B

A

A B

S T E P 1 2

With cut off wheels or a saw, remove the four (two are circled) rear wall ledges. These support the folding floor extensions.

Cut as flush to the rear wall as possible.

S T E P 1 3

Remove the rear wall carpeting.

HD Series Only

With cutting wheels or a saw, cut the threaded studs from the rear wall(B). Cut as flush to the rear wall as possible.

1500 Series Only

With a set of pliers, work the threaded studs(B), until they break free from the rear wall. With an Unibit®, enlarge these holes to an 1/2-inch diameter.

S T E P 1 4

Spray the areas that have been cut with paint. This is to prevent any rust from forming.

S T E P 1 5

Mount the driver's and the passenger's seat belt retracting units, c-pillars and rear door sill plates back into place.

1500 Series Trucks, go to STEP 19.

SB-GM-SLVCRW/10W1v2_INSTR_SKU#011173

HD Series Trucks Only

S T E P 1 6

Place the pair of supplied wax square into place. Passenger's side(pictured):

Place one of the supplied wax squares onto the lower left corner of the same emboss metal that the threaded stud was located on.

Driver's side(not pictured):

Place one of the supplied wax squares onto the lower right corner of the same emboss metal that the threaded stud was located on.

HD Series Trucks Only

S T E P 1 7

Thread the supplied pair of socket cup set screws into the Stealthbox®, leaving 3/4-inch of thread exposed. Position the Stealthbox® in the mounting location and press onto the Stealthbox® firmly.

Remove the Stealthbox® carefully, leaving the wax squares in place. The socket cup set screws will leave impressions in the wax.

HD Series Trucks Only

S T E P 1 8

Note: Before drilling, make sure that you are not going to be drilling into any gas lines, electrical wiring or anything else that might cause a reduction in your weekly pay. Always wear eye protection when drilling!

With a drill and a 1/2-inch drill bit, drill through the impression made in the wax square and through the cab wall.

Remove the wax squares, as seen in the picture at left.

S T E P 1 9

Place the rear wall carpet back into place.

Feel for both drilled holes in the rear wall through the carpeting. With an utility knife cut an X that is in line with these drilled holes.

This is to allow the pair of socket cup set screws to pass through the carpeting, once the Stealthbox® is in place.

Page 2 • JL Audio, Inc 2006 Continued on Next Page
