1080 Backup battery

DANGER

Use only the battery specified in the parts list for your computer. Any other battery could ignite or explode.

For access, remove these FRUs in order:

v“1010 Battery pack” on page 83

v“1020 Optical drive or second battery or travel cover” on page 84

v“1070 Keyboard” on page 95

Table 17. Removal steps of backup battery

1

2

When installing: Make sure that the battery connector is attached firmly.

Removing and replacing a FRU 99
