Lightolier specifications Lighting Systems Baselyte-BSL14, Page  of, Ordering Information

	Lighting Systems  Baselyte-BSL14
Page  of 7	 Light T5 HO Semi-Indirect

Ordering Information

Weight = 3.0 lb./ft





Family Distribution

Lamp Type No. of Lamps

Housing

Module Length

Wiring Voltage Ballast

Finish

BSL		5
	5 = Semi-Indirect

H		01
H = T5 HO	01 = 1 Light

LN

LN = Perforated

04 = 4’

08 = 8’

12 = 12’

1 = 1cct.

3= 1cct. w/EC/NL

5 = 1cct.

w/EM Battery 7 = 1cct.

w/Dimming 8 = 1cct. w/1cct.

Thru wire

Note: Please consult wiring section of spec sheets for more wiring options.

D = Dual 120V		E = Standard
	& 277V		<10% THD
1 = 120V		F = Standard
2 = 277V			<10% THD
			w/fusing

Note: Option‘D’ is standard. Voltage options 1 and 2 are only available with EM Battery and Dimming wiring options.

C = Custom Color

W = Standard

White

Specifications

Features

1.Housing: die-formed 20ga. cold rolled steel

2.End Set: die-cast metal with baked powder coat finish

3.Lamping: one T5 HO lamp

4.Configuration: 4’, 8’ and 12’ module lengths or continuous rows

5.Ballasts: electronic 120V or 277V

Finish

High-quality white powder coat with textured matte finish.

Custom colors available. Consult factory.

Mounting

Aircraft cable gripper is tamper-resistant and provides infinite vertical adjustment capability. Aircraft cable, crimp and cable gripper independently tested to meet stringent safety requirements.

Electrical

All luminaires are factory pre-wired to module ends with quick-wire connectors.

Joints & Intersections

Self-aligning joining system with hands-free pre-joining wire access.

Labels

UL, CSA standards.

Ordering Instructions

Individual Fixtures

1.Determine the number of individual modules required

2.Order one end set per module

3.Order one non-power mount per module

4.Order one power mount per module

Continuous Rows*

1.Determine run length

2.Order the appropriate number and length of modules for complete run

3.Order one end set for each run

4.Order one non-power mount for each module

5.Order one power mount per run

6.Order one joiner per module minus one (e.g. 3 modules requires 2 joiners)

*Note: Some runs may require additional power mounts. Please see the ‘Run Configuration’ table on the next page for more details.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lightolier a Genlyte Companywww.lightolier.com 631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710 We reserve the right to change details of design, materials and finish.

© 2005 Genlyte Group LLC • 0205 Rev.1
