This allows you to select the peripheral equipment you have

connected to the audio and video connectors.

1. Select Connections.

2. Press the cursor right.

3. Select the input to which the peripheral equipment is

connected.

>When you select EXT1,EXT2,EXT3,HDMI 1,

HDMI 2,Side or Digital Audio In, a list appears

which allows you to identify which type of peripheral

equipment is attached to this input.

4. Press the cursor right again to enter the list of types of

peripherals connected to the selected input.

5. Select the peripheral equipment with the cursor up/down.

Digital Audio In

If a peripheral equipment has a digital audio output, you can

connect this with a single cable to the TV’s DIGITAL

AUDIO IN connector.

In the Connections menu, assign the Digital Audio In to the

corresponding external input to which your peripheral

equipment is connected.

In addition to accepting audio input via Digital Audio In,the

TV can output encoded Dolby Digital audio via the

DIGITAL AUDIO OUT connector to an external amplifier

or receiver.If your amplifier or receiver has a matching

connector for Digital Audio In,you can connect it with a

single cable to the TV's DIGITAL AUDIO OUT.

See To make video and audio connections,Connect a Home

Cinema amplifier,p. 52.

Select your connections EN

33

Select a Decoder channel number

This allows you to define one or more channel numbers as

decoder channel numbers when a decoder or a descrambler is

connected to EXT1 or EXT2.

1. Select the channel number under which you have stored the

programme that comes from your decoder or descrambler.

2. Select Status.

3. Select the input used to connect your decoder: None,

EXT1 or EXT2.

<Select None if you do not want the selected channel

number being activated as a decoder channel number.

Info

TV menu

Installation Decoder

Channel

Status

.............

Time zone

Channels

Preferences

Connections

Decoder

Factory settings

Software upgrade

Info

TV menu

Installation Connections

EXT1

EXT2

EXT3

HDMI 1

HDMI 2

Side

Digital Audio IN

.............

Time zone

Channels

Preferences

Connections

Decoder

Factory settings

Software upgrade
