Rosewill RUC-6181 How to charge other mobile devices, Care & Troubleshooting Tips

How to charge other mobile devices

This charger can be use to charge mobile devices such as mobile phones, music players, PSP, Blackberry and digital cameras which have USB connection.

Note Your power adapter may look different from the one pictured here.

	1.	Connect the device adapter (not supplied) to USB power
		adapter and the mobile device.
	2.	Insert this USB Power Adapter into the wall power outlet.
		The LED will light up
p	3.	Disconnect from charger after charging completed.
e
r
a
t
u
r
e	Care & Troubleshooting Tips:
	z	To shut off power completely you must disconnect this
		USB power adapter from its power source.
	z	Never open this USB power adapter. This unit is a high
		voltage device and disassembly will invalidate your
		warranty, may damage your devices and cause possible
		injury to you.
	z	Before using this USB Power adapter, please check the
		USB port ensure there are no foreign objects within.
	z	While operating this USB power adapter, be sure that you
		always hold on each side and keep your fingers away from
		the metal parts.
	z	While operating this USB power adapter, make sure that
		sufficient airflow is available to prevent overheating.
	z	Never use force while connector USB connector the USB
		slots or AC plug with wall power outlets. If the connector
		and port do not smoothly join, make sure the connector
		matches the port and both ends are correctly aligned.
	z	Clean this USB power adapter with a clean dry cloth.
		Keeping the metal contacts clean will help maintain
		performance.
	z	If the LED status indicator does not light up make sure that
		the unit is properly plugged into the wall. If the indicator
		fails to light up when all ends are correctly connected.
		Please contact Rosewill for technical support to identify

the problem.

zIf your experience problems of insufficient or fail in charging from this USB power adapter, please check the power consumption of your devices. For example, charging an i-Phone require at least 5V 1,000mA. The problem will occur when you are simultaneously charging 3 i-Phone on this charger. According to the specification, you will only get 670mA from each USB port when sharing power from USB adapter with 3 units connected. 670mA is insufficient for i-Phone or i-Pod.

AC Plug Types

Specifications

Input: AC100V-240V ~60/50Hz

USB Power Output: DC 5.0V, 2000mA for 1 USB 5.0V, 1000mA for 2 USB 5.0V, 670mA for 3 USB 5.0V, 500mA for 4 USB

Operating Temperature: 0℃~+40℃

Storage Temperature: -20 ℃~+65℃

Thank you for purchasing a quality Rosewill Product.

Please register your product at: www.rosewill.com for complete warranty information and future support for your product.
