6Attach the window filler panels to the cabinet.

6-1 Install the top "L" shaped cannel with		three Type B screws	provided.
6-2 Slide the window filler panels and their frames into the channels on the
top and bottom of the cabinet and assemble them to the cabinet using
six Type B screws	.

7Attach the support brackets to the cabinet.

7-1 Select the	Type D support bracket		position that will place the bracket
near the outermost point on the window sill. In most cabinets this will
be the first set of holes. Using			eight Type B screws	, attach the
support brackets to each side of the cabinet bottom.
7-2 Thread the	Type C bolts	into the support brackets, making sure the
cabinet maintains a slightly downward slant to the outside.
A 1/4" slant, from the cabinet front to the rear, is necessary.
Use the level to determine the slant.

8Attach the seal strip to the window.

8-1 Cut the adhesive-backed foam seal strip to the window width.

8-2 Remove the backing from the seal strip and attach the strip to the underside of the bottom window.

Top Channel

Type B

Screws

Type C Bolts

9Install the cabinet in the window.

9-1 Place the cabinet into the window with the frame on the top of the cabinet positioned just in front of the bottom window.

Pull the window down until it rests on the cabinet just behind the top channel of the frame on the top of the cabinet.

9-2 Locate three screw holes along the cabinet bottom front edge.

Center the cabinet, side to side, in the window and mount it to the

window stool using t hree Type A screws .

Top

Channel

E-15
