5.7 Global Bypass
Because Duende plug-ins cause a noticeable latency at higher host buffersettings, the bypass button provided by the DAW can
cause an undesirable shift in time. For this reason a latency-free global bypass (In/Out) button is included. When this is engaged
the audio is still passed to and from Duende, but is unchanged as all X-EQ processing (including input and output gains) are
bypassed. This gives a smooth, glitch free bypass function and we recommend that you use this method every time.
5.8 X-EQ Band Parameters and Control Range
Band	Gain	Frequency	Q
HP Filter	n/a	20Hz – 1020Hz	0 – 48dB/oct in 6dB steps
Low Shelf	±20dB	20Hz – 1020Hz	0.3 – 10.3
Midband 1	±20dB	20Hz – 20kHz	0.3 – 10.3
Midband 2	±20dB	20Hz – 20kHz	0.3 – 10.3
Midband 3	±20dB	20Hz – 20kHz	0.3 – 10.3
Midband 4	±20dB	20Hz – 20kHz	0.3 – 10.3
Midband 5	±20dB	20Hz – 20kHz	0.3 – 10.3
Midband 6	±20dB	20Hz – 20kHz	0.3 – 10.3
High Shelf	±20dB	500Hz – 20kHz	0.3 – 10.3
LP Filter	n/a	500Hz – 20kHz	0 – 48dB/oct in 6dB steps
