Free

external

PCG-R505TL

PCG-R505TLK

Sony VAIO® R505 SuperSlim ProNotebook

Mobile Intel® Celeronprocessor 650 MHz1

3.75 lbs. light, about 1" thin

12.1" XGA TFT screen

Integrated Ethernet

128 MB SDRAM/15.0 GB3 hard drive

Free external CD-ROM drive

Sony VAIO SlimDockTM docking station sold separately.

SPECIFICATIONS

-ROM

drive

CD



ADDITIONAL FEATURES

• Mobile Intel® Celeronprocessor 650 MHz1

3.75 lbs. light, about 1" thin

• 12.1" XGA (1024 x 768) TFT screen

10Base-T/100Base-TX integrated Ethernet with



RJ-45 interface

• 15.0 GB3 hard drive

• Durable magnesium-alloy case

• 128 MB SDRAM (expandable to 320 MB max.)

• Integrated V.90 modem

New high-capacity lithium-ion battery

Responsive, nearly full-size tactile keyboard (95%)

i.LINK® (IEEE 1394) S400 interface4 — supports



high-speed digital video, audio and data transfer



capabilities among equipped Sony products

• MagicGateMemory Stick® media slot

Intel® 815EM integrated graphics chip with



Intel® D.V.M. technology including up to 11 MB



SDRAM (shared)

Model

PCG-R505TL

PCG-R505TLK

Processor

Mobile Intel® Celeronprocessor 650 MHz1

Cache Memory

256 KB integrated on-die level 2

Bus Speed

100 MHz1

Bus Architecture

PCI/AGP

LCD

12.1" XGA TFT

Graphics

Intel® 815EM integrated graphics chip with Intel® D.V.M. technology including up to 11 MB SDRAM (shared)

Digital Audio

Windows® sound system compatible 3D surround sound

MPEG

MPEG1 digital video

Supports full screen playback

Standard RAM

128 MB SDRAM, expandable to 320 MB

Hard Drive

15.0GB3 fixed

Floppy Disk Drive

Optional SlimDock1.44 MB, 3.5" Optional external USB 1.44 MB, 3.5"

Size

Approx. 1" X 11" X 9.4" (H x W x D)

Weight

3.75lbs. (with standard battery)

Supplied Accessories

Standard Lithium-Ion battery, AC adapter, Power cable

Optional Accessories

SlimDockTM docking station with DVD/CD-RW combination drive (PCGA-DSM5)

SlimDockTM docking station with DVD drive (PCGA-DSD5)

MagicGateMemory Stick® media:

32 MB (MSG-32A), 64 MB (MSG-64A), 128 MB (MSG-128A)

Standard-capacity battery (PCGA-BP2R) Double-capacity battery (PCGA-BP4R) USB mouse (PCGA-UMS1/A)

Additional AC adapter (PCGA-AC19V1) Carrying case (PCGA-CCF)

New Carrying case (PCGA-CCR5) External USB floppy drive (PCGA-UFD5) External CD-RW drive (PCGA-CDRW52)

Service

One year limited Express Service6

Limited Warranty

One year parts and labor (90 days without registration)7

Telephone Support Hardware: One year 7

Software and operating system: 90 days7

Built-in stereo speakers

1 type II PC card slot with CardBus support

• 2 USB ports

Bundled standard battery, AC adapter and



power cord

Center Jog Dialscrolling function

1

MHz denotes microprocessor internal clock speed; other factors may affect application



performance.

2

Requires payment of additional fees or subscription for use.

3

GB means one billion bytes when referring to hard drive capacity. Accessible capacity



may vary.

4

i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394



connector. All products with an i.LINK connector may not communicate with each other.

5

Estimated battery life. Actual battery life may vary on usage.

6

Certain restrictions apply to Express Repair Service.

7

From date of purchase upon registration.

8

Other restrictions apply

Sony Electronics Inc.

Personal Network Solutions Company

16765 West Bernardo Drive, San Diego, CA 92127 For more information: 1.800.4SONYPC (476-6972) Web address: www.sony.com/vaio

Computer Interface: The computer industry lacks standards, and therefore, there are a multitude of varying software packages and add-on hardware options. This personal computer is not manufactured to any specific software, and Sony does not and cannot make any warranty or representation with respect to the performance of this product with any particular software packages and/or non-Sony add-on hardware option except those mentioned in this document. Sony hereby disclaims any representations or warranty that this product is compatible with any combination of products you may choose to connect. While Sony representatives or Sony authorized dealers may be able to assist you and may make recommendations, they are NOT authorized to vary or waive this disclaimer. Purchasers must determine for themselves the suitability and compatibility of the hardware and software in each and every particular instance. Some pre-installed software titles may not include full documentation. Software titles pre- installed on the Sony Notebook Computer are subject to change without notice. Simulated graphic shown on display.

Modem

Integrated V.90 modem

Keyboard

83 key QWERTY layout Approx. 18mm key pitch 2mm stroke

Pointing Device

Electro-Static touch pad

Speakers

Built-in stereo speakers

Microphone

External Microphone

Battery

Lithium-Ion battery

Supports standard Lithium-Ion battery (supplied) or double-capacity Lithium-Ion battery (optional)

Battery Life

3.0–4.5 hours (with supplied standard battery)5 6.0–8.0 hours (with double-capacity battery)5

PC Card Slots

Supports one type II card

CardBus support

Other Interfaces

On main unit: USB (2), i.LINK® (IEEE 1394) S400, headphone out, RJ-11 phone jack, MagicGateMemory Stick® interface,

RJ-45 10Base-T/100Base-TX Ethernet, new center Jog Dial, mic-in Jack or External mic-in, Security lock

Power Requirements

73.2 watts maximum (19.5V DC / AC100-240V)

INCLUDED SOFTWARE

Operating System

PCG-R505TL: Microsoft® Windows® Millennium Edition

PCG-R505TLK: Microsoft® Windows® 2000 Professional

Software Applications

Adobe Acrobat® Reader

Adobe PhotoDeluxe® Home Edition (Windows® Me)

ArcSoft® PhotoPrinter2000 Pro (Windows® Me)

Easy Systems Drag'n DropCD

Quicken® New User Edition

McAfee® VirusScan®

Microsoft® Word 2000

QuickTime

RealNetworks® RealPlayer®

Sony DVgate

Sony Media Bar

Sony MovieShaker

Sony OpenMGJukebox

Sony PictureGear

Sony Smart Capture

Sony VisualFlow

WinDVD® 2000

Online Center

VAIO Support Agent (Windows® Me)

America Online® 2 (Windows® Me)

Compuserve® 2000 2 (Windows® Me)

EarthLink Network TotalAccess®2

Microsoft® Internet Explorer (Windows® Me)

Netscape Communicator®

Prodigy Internet® 2 (Windows® Me)

VAIO® Support Agent

©2001 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, i.LINK, Memory Stick and VAIO are registered trademarks and DVgate, Jog Dial, Media Bar, PictureGear and R505 SuperSlim Pro are trademarks of Sony. Intel and Pentium are registered trademarks of Intel Corporation. Microsoft and Windows are trademarks of Microsoft Corporation. All other trademarks are trademarks of their respective owners. This product meets the standards of the International Energy Star Program for energy efficiency. Features and specifications are subject to change without notice. Non-metric weights and measurements are approximate.

Printed in U.S.A. 06/01

Power Management

Energy Star compliant

Advanced power management - ACPI compatible
