REFRIGERATOR LINER PARTS
For Models: ED2FHEXVQ00, ED2FHEXVT00, ED2FHEXVB00, ED2FHEXVL00, ED2FHEXVS00
(White) | (Biscuit) | (Black) | (Stainless VCM) (Stainless) | ||
|
|
| Illus. | Part |
|
|
|
| No. | No. | DESCRIPTION |
|
|
| 1 |
| Liner (Not A |
|
|
|
|
| Serviceable Part) |
|
|
| 2 | 2194744 | Escutcheon, Meat |
|
|
|
|
| Pan Control |
|
|
| 3 | 2182757 | Slide, Meat |
|
|
|
|
| Pan Control |
|
|
| 4 | 2257741 | Louver |
|
|
| 5 | 2256035 | Bracket, Dual |
|
|
|
|
| Crisper Light |
|
|
| 6 | 489290 | Screw |
|
|
| 7 | 2311637 | Wire Harness, |
|
|
|
|
| Crisper Light |
|
|
| 8 | 1123919 | Bracket, Retainer |
|
|
| 9 | 2209753 | Air Diffuser |
|
|
|
|
| Assembly |
|
|
| 10 | 2152019 | Air Diffuser |
|
|
|
|
| Cover |
|
|
| 11 | 2150331 | Cover, Conduit |
|
|
| 12 | 486298 | Screw |
|
|
| 13 | 2162085 | Socket |
|
|
| 14 | 2256126 | Reservoir |
|
|
| 15 | 527949 | Light Bulb |
|
|
| 16 | 2209769 | Light Lens |
|
|
| 17 | 488280 | Screw (2) |
W10177406 | 3 |
