ASA

regolatore automatico sale/

WHS

Sensore durezza acqua

C1

Condensatore spunto

CB

Scheda controllo

CULCD

Interfaccia display LCD

DB

Scheda display

DUB

Display - scheda programmi

DLB

Display avviamento



ritardato

DPM

Motore pompa scarico

DD

Bobina dos. detersivo

DON

Sensore torbidità acqua

DR

Bobina dos. brillantante

DS

Interruttore porta

DVH

Deviatore di flusso



(alta tensione)

DVL

Deviatore di flusso



(bassa tensione)

FM

Flussometro

HEWI

Resistenza riscald.

IF

Filtro antidisturbi

LS6

Interrutore acqua-stop

L

Linea

MS

Interruttore On/Off

NTC

Sonda temperatura

N

Neutro

OWI

Indic. acqua, ottico

PRG

Connettore per



programmazione

RV

Interruttore durezza acqua

RE2

Relè riscaldamento

RR SA

Contatto reed sale

RR RA

Contatto reed brillantante

SAB

Sonda spruzzat. bloccato

SPM

Motore pompa lavaggio

THS1

Termostato sicurezza

THS2

Fusibile

TBL

Morsettiera principale

TL

Termolimitatore

UB

Scheda programmi

VM

Motore ventilatore asciug.

WV1

Elettrovalvola carico

WV2

Elettrovalvola rigenera

WI

Indic. acqua (a membrana)

ZW

Elettrovalvola multizone

00

Nero

66

Blù

88Grigio

99Bianco

SCHEMA FUNZIONALE

Whirlpool Europe S E R V I C E Customer Service

ADP 4962 IX 8542 962 38790

23.10.2002 / Page 9 Doc. No: 4812 718 18247

Page 9
Image 9
Whirlpool 4962, IX service manual Schema Funzionale, WV2
