Husqvarna 465, 460, 455e manual General rules, Cutting equipment designed to reduce kickback

Page 11

GENERAL SAFETY PRECAUTIONS

General rules

•Only use cutting equipment recommended by us! See instructions under the heading Technical data.

•Keep the chain’s cutting teeth properly sharpened! Follow our instructions and use the recommended file gauge. A damaged or badly sharpened chain increases the risk of accidents.

•Maintain the correct depth gauge setting! Follow our instructions and use the recommended depth gauge clearance. Too large a clearance increases the risk of kickback.

•Keep the chain properly tensioned! If the chain is slack it is more likely to jump off and lead to increased wear on the bar, chain and drive sprocket.

•Keep cutting equipment well lubricated and properly maintained! A poorly lubricated chain is more likely to break and lead to increased wear on the bar, chain and drive sprocket.

Cutting equipment designed to reduce kickback

!

WARNING! Faulty cutting equipment or

the wrong combination of bar and saw



chain increases the risk of kickback!



Only use the bar/saw chain combinations



we recommend, and follow the filing



instructions. See instructions under the



heading Technical data.

The only way to avoid kickback is to make sure that the kickback zone of the bar never touches anything.

By using cutting equipment with ”built-in” kickback reduction and keeping the chain sharp and well- maintained you can reduce the effects of kickback.

Guide bar

The smaller the tip radius the lower the chance of kickback.

Saw chain

A chain is made up of a number of links, which are available in standard and low-kickback versions.

IMPORTANT! No saw chain design eliminates the danger of kickback.

!

WARNING! Any contact with a rotating

saw chain can cause extremely serious



injuries.

Some terms that describe the bar and chain

To maintain the safety features of the cutting equipment, you should replace a worn or damaged bar or chain with a bar and chain combinations recommended by Husqvarna. See instructions under the heading Technical Data for a list of replacement bar and chain combinations we recommend.

Guide bar

•Length (inches/cm)

•Number of teeth on bar tip sprocket (T).

•Chain pitch (inches). The spacing between the drive links of the chain must match the spacing of the teeth on the bar tip sprocket and drive sprocket.

•Number of drive links. The number of drive links is determined by the length of the bar, the chain pitch and the number of teeth on the bar tip sprocket.

English – 11

Page 10 Page 12
Image 11
Page 10 Page 12
Contents English Symbols in the operator’s manual KEY to SymbolsSymbols on the machine Contents Dear Customer IntroductionWhat is what on the chain saw? What is WHAT?Before using a new chain saw General Safety PrecautionsChain brake and front hand guard Machine′s safety equipmentAlways use common sense Personal protective equipmentGeneral Safety Precautions Right hand guard Throttle lockoutChain catcher Muffler Stop switchCutting equipment Vibration damping systemCutting equipment designed to reduce kickback General rulesGeneral information on sharpening cutting teeth Sharpening your chain and adjusting depth gauge settingTensioning the chain Lubricating cutting equipment Rancher II, 460 Rancher II, 465 Rancher455e Rancher II, 455e Rancher II TrioBrake Needle bearing lubrication Filling with chain oilChecking chain lubrication Chain drive sprocketGuide bar Working with the chain AssemblyFitting the bar and chain Fitting a spike bumper Fuel Fuel HandlingLong-term storage Fuel safetyFueling Transport and storageCold engine Starting and StoppingStarting and stopping StartingStopping General working instructions Basic safety rulesWorking Techniques Before useGeneral rules Basic cutting technique Safe distance Tree felling techniqueDirectional cuts Felling directionClearing the trunk and preparing your retreat Felling cut Freeing a tree that has fallen badly How to avoid kickbackWhat is kickback? Cutting the trunk into logs General MaintenanceCarburettor adjustment Checking the inertia brake release Muffler Changing a broken recoil spring StarterChanging a broken or worn starter cord Tensioning the recoil springFitting the starter Air filterSpark plug Needle bearing lubricationCooling system Adjustment of the oil pumpAir Injection centrifugal cleaning Temperature 0C or colderTemperature -5C or colder Daily maintenance Weekly maintenance Monthly maintenance Maintenance scheduleTechnical data Technical DataRancher Engine Saw chain filing and file gauges Guide bar and saw chain combinationsEN ISO 121002010, ISO 149821998, EN ISO EC-declaration of conformityApplies to Europe only Page Original instructions 1154135-26
Related manuals
Manual 44 pages 48.45 Kb

455, 455e, 460, 465 specifications

The Husqvarna 460 and 455 series chainsaws are some of the most popular models in their class, recognized for their reliability, performance, and advanced technology. These machines are designed to meet the demands of both professionals and enthusiasts who require powerful tools for cutting firewood, felling trees, or performing tree maintenance.

The Husqvarna 460 is equipped with a robust 60.3 cc engine that delivers impressive power and efficiency. With a power output of approximately 3.6 kW, this chainsaw is capable of handling ambitious cutting tasks with ease. The design of the 460 includes a low-vibration system that significantly reduces operator fatigue during extended use. This is achieved through effective isolating features that dampen vibrations transferred to the user's hands, allowing for more comfortable operation over longer periods.

One of the standout features of the Husqvarna 460 is its X-Torq engine technology. This innovative design reduces fuel consumption by up to 20% while also decreasing harmful exhaust emissions. This is increasingly important for environmentally conscious users, as it allows for a greener operation without compromising performance. The chainsaw is also equipped with an air injection system that effectively removes larger particles from the air before they reach the filtration system, ensuring cleaner air intake and extending the lifespan of the air filter.

On the other hand, the Husqvarna 455 Rancher is another exceptional model known for its versatility and robust design. Featuring a slightly smaller 55.5 cc engine, it offers a solid power output of around 2.6 kW, making it suitable for a wide range of tasks from cutting firewood to clearing brush. The 455 Rancher shares many of the same technological advancements as the 460, including the X-Torq engine and low-vibration technology, providing users with similar benefits in terms of efficiency and comfort.

Both models feature an adjustable oil pump for better chain lubrication, ensuring smooth operation and prolonging the chain's life. Additionally, the easy access air filter and tool-less chain tensioning allow for quick maintenance and adjustments in the field, making them user-friendly choices.

Overall, the Husqvarna 460 and 455 series chainsaws combine power, efficiency, and advanced technology, catering to the needs of both casual users and professionals alike. Their thoughtful design and robust performance establish them as reliable tools in any cutting task, making them a top choice for those in need of high-quality chainsaws.
