Poulan PD20H42STA owner manual Decals, Wheels and Tires, Decal Oper

Page 39

TRACTOR - - MODEL NUMBER PD20H42STA PRODUCT NO. 954 56 95-09

DECALS





7



2

11





16

4

























9

6

5

14

4

3

10

2

20





1





8

12

13

KEY

PART



NO.

NO.

DESCRIPTION

1

157032

Decal Oper

2176303 Decal Fender Auto

3186164 Decal Hood LH

4185809 Decal Side Panel Logo

5170851 Decal HP Engine

6170563 Decal Warning, Keep Hand Away

7185440 Decal Replacement Parts

8179128 Decal Deck "B" 42"

9172740 Decal Fender Logo

10157140 Decal Fender Danger E/F

11172743 Decal Ins Strg Whl

12173587 Decal Fend Reflector Rh

WHEELS AND TIRES

1

25,8

4,10

7

3,9

6

11

KEY PART

NO. NO. DESCRIPTION

13173589 Decal Fend Reflector Lh

14160396 Decal V-Belt Schematic

16

186163

Decal Hood Rh

20

145005

Decal Bat Dan/Psn

- -

169210

Decal By Pass Lt Hydro

-- 179768X428 Pad Footrest LH

-- 179769X428 Pad Footrest RH

- -

138311

Decal Handle Lft Height Adjust

- -

184617

Manual Owner's (English)

- -

184618

Manual Owner's (French)

KEY

PART



NO.

NO.

DESCRIPTION

1

59192

Cap Valve Tire

2

65139

Stem Valve

3170455 Tire F T 15 X 6 0 - 6 Service

459904 Tube Front (Service Item Only)

5106732X421 Rim Asm 6"front Service

6

278H

Fitting Grease (Front Wheel Only)

7

9040H

Bearing Flange (Front Wheel nly)

8106108X421 Rim Asm 8"rear Service

9170456 Tire R T 20x10-8 Service

107152J Tube Rear (Service Item Only)

11104757X421 Cap Axle Blk 1 50 X 1 00

- -

144334

Sealant, Tire ( 10 oz. Tube)

NOTE: All component dimensions given in U.S. inches 1 inch = 25.4 mm

39
