Cub Cadet CS3210, CS 2210 warranty Troubleshooting, Problem Cause Remedy

Page 16

Troubleshooting

8

Problem

Cause

Remedy

Engine Fails to start

1.

Throttle lever not in correct starting position.

1.

Move throttle lever to FAST or START









position.



2.

Spark plug wire disconnected.

2.

Connect wire to spark plug.



3.

Choke not in CHOKE position (if equipped).

3.

Move choke lever to CHOKE position.



4.

Fuel tank empty or stale fuel.

4.

Fill tank with clean, fresh gasoline.



5.

Engine not primed (if equipped).

5.

Prime engine as instructed in Engine Manual.



6.

Faulty spark plug.

6.

Clean, adjust gap, or replace.



7.

Blocked fuel line.

7.

Clean fuel line.



8.

Engine flooded.

8.

Wait a few minutes to restart, but do not









prime.











Engine runs erratic

1.

Spark plug boot loose.

1.

Connect and tighten spark plug boot.



2.

Unit running on CHOKE (if equipped).

2.

Move choke lever to OFF position.



3.

Blocked fuel line or stale fuel.

3.

Clean fuel line; fill tank with clean, fresh









gasoline.



4.

Low engine RPM.

4.

Always run engine at full throttle.



5.

Water or dirt in fuel system.

5.

Drain fuel tank. Refill with fresh fuel.



6.

Dirty air cleaner.

6.

Refer to engine manual.



7.

Carburetor out of adjustment.

7.

See authorized service dealer.











Engine overheats

1.

Engine oil level low.

1.

Fill crankcase with proper oil.



2.

Dirty air cleaner.

2.

Refer to engine manual.



3.

Carburetor not adjusted properly.

3.

See authorized service dealer.











Occasional skips

1.

Spark plug gap too close.

1.

Remove spark plug and adjust gap to .030”.

(hesitates) at

2.

Carburetor idle mixture adjustment

2.

See authorized service dealer.

high speed



improperly set.























Excessive Vibration

1.

Loose parts or damaged impeller.

2.

See authorized service dealer.











Unit does not discharge

1.

Discharge area clogged.

1.

Stop engine immediately and disconnect









spark plug wire. Clean flail screen and inside









of discharge opening.



2.

Foreign object lodged in impeller.

2.

Stop engine and disconnect spark plug wire.









Remove lodged object.



3.

Low engine RPM.

3.

Always run engine at full throttle.











Rate of discharge slows

1.

Low engine RPM.

1.

Always run engine at full throttle.

considerably or composition

2.

Chipper blade dull.

2.

Replace chipper blade or see your authorized

of discharged material







service dealer.

changes

























16

Page 15 Page 17
Image 16
