REPAIR PARTS SNOW THROWER - - MODEL NO. PR8527ES (96192001705)

CHASSIS / ENGINE / PULLEYS

1

KEY

PART



NO.

NO.

DESCRIPTION

1

192213

BELT COVER

2

179157

IMPELLER PULLEY

3

419744

TRACTION BELT

4

408007

IMPELLER BELT

2

3

401.04.019-A

NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm

IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty.

34
