Meade MAX-ACF instruction manual MaleTHE OTA, Optical Tube Assembly

Page 9

Optical Tube Assembly

MAX-ACF is delivered with a 20” Advanced Coma-Free™ Optical

Tube Assemblie. Its 20” OTA integrates seamlessly with MAX-ACF

German Equatorial Mount. Together you get pinpoint stars from

Meade's unique Advanced Coma-Free optical system:

•Zero expansion carbon fiber body

•Advanced Coma-Free optics

•Electronic Collimation

•Integrated Dew Heater

•OTA fan for quick cool down

•Digital Electronic Focus with Presets

Viewfinder

Optical Tube Assembly (OTA)

2"

Dust Cover2"Accessory

Eyepiece

Adapter

OTA Alignment Bolts (concentric)

2" Star Diagonal

Visual

Back

OTA

Panel

OTA

MaleTHE OTA

Dovetail

Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the	9
Sun. Do not look through the telescope as it is moving.
