Fujitsu C2330 manual Hard Disk Security Submenu of the Security Menu

Page 24

L i f e B o o k C S e r i e s N o t e b o o k B I O S

Hard Disk Security Submenu of the Security Menu

The Hard Disk Security Submenu is for configuring hard disk security features.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Hard Disk Security

Item Specific Help

Primary Master

Password Is:

Clear

Set Primary Master Password:

[Enter]

Password Entry

on Boot:

[Enabled]

F1 Help

Select

Item

-/Space

Change

Values

ESC Exit

Select

Menu

Enter

Select

Sub-Menu

Figure 14. Hard Disk Security Submenu

F9 Setup Defaults

F10 Save and Exit

Table 14: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu

Menu Field

Options

Default

Description









Primary Master

___

Clear

Display-only. Default is Clear. When the Primary Master Password has been

Password Is:





set, the field changes to Set. When this password is set, the primary hard disk







drive cannot be used in another system unless the password is entered.









Set Primary

___

[Enter]

Sets, changes or cancels the Primary Master Password. The Primary Master

Master





Password may be up to seven characters long and must include only letters or

Password:





numbers (no symbols). Passwords are NOT case-sensitive. When a Primary







Master Password is set, it must be used to access the primary hard drive if it is







used in another system. Note that the password will not take effect until the







system has been rebooted.









Password Entry

Disabled

[Enabled]

When disabled, it is not necessary to enter a Hard Disk Password before boot-

on Boot:

Enabled



ing. The hard disk is still password-protected without entering a password.









24
