Page 40

Chapter 2 Installation

Installing the Router

Perform the following steps to connect the router’s console port to a terminal or PC:

Step 1 Connect the RJ-45 connector on one end of the light blue cable to the console port on the router.

Step 2 Connect the DB-9 connector on the other end of the cable to the terminal or PC.

If you have experience configuring Cisco routers and prefer to use the CLI, refer to the Cisco 800 Series Routers Software Configuration Guide for instructions on configuring the router.

Connecting the AC Adapter

To connect the power supply, follow the steps given after Figure 2-6. (Figure 2-6depicts a Cisco 837 router, but it also applies to the SOHO 97 router. The connection procedure applies to both the Cisco 837 router and the SOHO 97 router.)

Warning The device is designed to work with TN power systems.

Warning This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that a fuse or circuit breaker no larger than 120 VAC, 15A U.S. (240 VAC, 16A international) is used on the phase conductors (all current-carrying conductors).

Warning This equipment is intended to be grounded. Ensure that the host is connected to earth ground during normal use.



Cisco 837 Router and SOHO 97 Router Hardware Installation Guide

2-16

78-14781-02
