Standard CMOS Features



















CMOS Setup Utility-Copyright (C) 1984-2005 Award Software









Standard CMOS Features







Date (mm:dd:yy)

Wed, May 11 2005



Item Help



Time (hh:mm:ss)



10:40:9



Menu Level`











Change the day, month,

` IDE Channel 0 Master

[None]



year



` IDE Channel 0 Slave

[None]







` IDE Channel 1 Master

[None]



<Week>



` IDE Channel 1 Slave

[None]



Sun. to Sat.

` IDE Channel 2 Master

[None]







` IDE Channel 3 Master

[None]



<Month>



Drive A



[1.44M, 3.5"]

Jan. to Dec.











Floppy 3 Mode Support

[Disabled]



<Day>













1 to 31 (or maximum



Halt On



[All, But Keyboard]

allowed in the month)



Base Memory



640K



<Year>





Extended Memory

127M



1999 to 2098



Total Memory



128M







KLJI: Move

Enter: Select

+/-/PU/PD: Value

F10: Save

ESC: Exit

F1: General Help



F5: Previous Values

F6: Fail-Safe Defaults

F7: Optimized Defaults



















Date













The date format is <week>, <month>, <day>, <year>.









Week

The week, from Sun to Sat, determined by the BIOS and is display only



Month

The month, Jan. Through Dec.









Day

The day, from 1 to 31 (or the maximum allowed in the month)





Year

The year, from 1999 through 2098







Time

The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military- time clock. For example, 1 p.m. is 13:00:00.

IDE Channel 0/1 Master, Slave

IDE HDD Auto-Detection Press "Enter" to select this option for automatic device detection. IDE Device Setup. You can use one of three methods:

Auto

Allows BIOS to automatically detect IDE devices during POST.(default)

None

Select this if no IDE devices are used and the system will skip the automatic



detection step and allow for faster system start up.

Manual

User can manually input the correct settings

Access Mode

Use this to set the access mode for the hard drive. The four options are:



CHS/LBA/Large/Auto(default:Auto)

IDE Channel 2/3 Master

IDE HDD Auto-Detection Press "Enter" to select this option for automatic device detection. Extended IDE Drive SATA devices setup. You can use one of two methods:

Auto

Allows BIOS to automatically detect SATA IDE devices during POST.



(Default value)



None

Select this if no SATA IDE devices are used and the system will skip the



automatic detection step and allow for faster system start up.

Access Mode

Use this to set the access mode for the hard drive. The two options are:



Large/Auto(default:Auto)







GA-8VM800M-775 Motherboard

- 32 -
