Gigabyte GA-8VM800M-775 user manual Integrated Peripherals, Raid

Page 36

English

2-3

Integrated Peripherals























CMOS Setup Utility-Copyright (C) 1984-2005 Award Software











Integrated Peripherals







OnChip IDE Channel 0

[Enabled]





Item Help



OnChip IDE Channel 1

[Enabled]



Menu Level`



OnChip Serial ATA



[Enabled]









SATA Mode





[RAID]









AC97 Audio





[Auto]









USB 1.1 Controller



[Enabled]









USB 2.0 Controller



[Enabled]









USB Keyboard Support

[Disabled]









USB Mouse Support



[Disabled]









Onboard H/W LAN



[Enabled]









OnBoard LAN Boot ROM

[Disabled]









Onboard Serial Port 1

[3F8/IRQ4]







Onboard Serial Port 2

[2F8/IRQ3]







Onboard Parallel Port

[378/IRQ7]







Parallel Port Mode



[SPP]







x

EPP Mode Select



EPP1.7







KLJI: Move

Enter: Select

+/-/PU/PD: Value

F10: Save

ESC: Exit

F1: General Help



F5: Previous Values

F6: Fail-Safe Defaults

F7: Optimized Defaults

















OnChip IDE Channel0











Enabled



Enable onboard 1st channel IDE port. (Default value)





Disabled



Disable onboard 1st channel IDE port.







OnChip IDE Channel1











Enabled



Enable onboard 2nd channel IDE port. (Default value)





Disabled



Disable onboard 2nd channel IDE port.







OnChip Serial ATA











Enabled



Enable VT8237R Plus Serial ATA supported. (Default value)





Disabled



Disable VT8237R Plus Serial ATA supported.







SATA Mode















RAID



Set onboard SATA mode to RAID. (Default value)





IDE



Set onboard SATA mode to IDE.









AC97 Audio















Auto



Enable onboard AC'97 audio function. (Default value)





Disabled



Disable this function.









USB 1.1 Controller











Disabled



Disable USB 1.1 controller.









Enabled



Enable USB 1.1 controller. (Default value)







USB 2.0 Controller











Disabled



Disable USB 2.0 controller.









Enabled



Enable USB 2.0 controller. (Default value)







USB Keyboard Support











Enabled



Enable USB keyboard support.









Disabled



Disable USB keyboard support. (Default value)





GA-8VM800M-775 Motherboard

- 36 -
