Features

Delphi Series S48SP, 35W 1x1 Brick

DC/DC Power Modules: 48V in, 3.3V/10A out

The Delphi Series S48SP, 1x1 Brick, 48V input, single output, isolated DC/DC converters are the latest offering from a world leader in power systems technology and manufacturing ― Delta Electronics, Inc. This product family is available in a surface mount or through-hole package and provides up to 35 watts of power or 10A of output current (3.3V and below) in a new 1x1 form factor (1.30”x0.96”x0.33”). The pinout is compatible with the industry standard 1x2 products. With creative design technology and optimization of component placement, these converters possess outstanding electrical and thermal performance, as well as extremely high reliability under highly stressful operating conditions. Typical efficiency of the 3.3V/10A module is better than 90%. All modules are fully protected from abnormal input/output voltage, current, and temperature conditions.

DATASHEET

DS_S48SP3R310_05222008

High efficiency: 90% @ 3.3V/10A

Industry standard 1x2 pinout

Size: 33.0 x 24.4 x 8.55mm (1.30”x0.96”x0.34”)

SMD and Through-hole versions

Fixed frequency operation

Input UVLO, OVP

OTP and output OCP, OVP (default is auto-restart)

Monotonic startup into normal and pre-biased loads

2250V isolation and basic insulation

No minimum load required

ISO 9001, TL 9000, ISO 14001, QS9000, OHSAS18001 certified manufacturing facility

UL/cUL 60950 (US & Canada) recognized, and TUV (EN60950) certified

CE mark meets 73/23/EEC and 93/68/EEC directive

OPTIONS

SMD module available

Remote On/Off

OTP and Output OVP, OCP mode, Auto-restart (default) or latch-up

Short pin lengths

Encapsulated case optional

APPLICATIONS

Optical Transport

Data Networking

Communications, including Wireless and traditional Telecom

Servers
