Page 31

ADMINISTRATOR/OTHERS (NOISE EMISSION)

Forwarding all sent or received data to the administrator (document administration function)

This function is used to forward all data sent and received by the machine to a specified destination (Scan to E-mail address, Scan to FTP destination, Scan to Network Folder destination, or Scan to Desktop destination). This function can be used by the administrator of the machine to archive all sent and received data. To configure the document administration settings, click [Application Settings] and then [Document Administration Function] in "Settings mode". (Administrator rights are required.)

The forwarding data, exposure, and resolution settings of sent and received data remain in effect.

When forwarding is enabled for data sent in fax mode:

The [Direct TX] key does not appear on the touch panel.

Quick online transmission and dialing using the speaker cannot be used.

Setting mode password

An administrator password is required to configure the machine settings using administrator rights. The settings can be configured from either the operation panel or by using a computer web browser. After setting up the machine, refer to "Settings mode" in the User’s Manual to set a new password.

The same administrator password is used for the operation panel and the Web page. If the administrator changes a password on the operation panel, the password will be valid when logging in to the Web page.

Password for logging in from a computer

As factory default, "Administrator" is the only account allowed to log in from a Web browser. By setting user authentication, "System Administrator" will also be allowed to log in from the Web browser. You can also specify a device account as a login user.

Noise emission

Noise emission values

The following shows noise emission values as measured according to ISO7779.

Sound power level LWAd





MX-6240N

MX-7040N

Operating



7.8 B

7.8 B

Standby



-

-









Sound pressure level LpAm

















MX-6240N

MX-7040N









Operating



59 dB

60 dB









Standby



-

-

Operating: with options MX-RB12 and MX-FN19.

Standby: "-" = less than background noise.

The factory default passwords for respective accounts are shown in the following.

Logging in as an "Administrator" or "System Administrator" allows you to manage all the settings available via Web browser.



Account

Password

User

user

users







Administrator

admin

admin







System administrator

sysadmin

sysadmin













Do not forget the new administrator password.
