Alteon Web Switch Hardware Installation Guide
Environmental Specifications
Condition | Operating Specification | Storage Specification |
Temperature | 0° to 40° C (+32° to +104° F) | |
Relative humidity | 5 to 85% | 5 to 95% |
| (40° C, 16 hour dwells at extremes) | 10° C/hour |
Altitude | up to 3,050 meters (10,000 feet) | up to 10,750 meters (35,000 feet) |
Shock | 10g, 1/2 sine wave, 11 msec | 60g, 1/2 sine wave, 11 msec |
Vibration, peak to peak | 0.005 in. max (5 to 32 Hz) | 0.1 in. max (5 to 17 Hz) |
displacement |
|
|
Vibration, peak | 0.25g (5 to 500 Hz) | 0.25g (5 to 500 Hz) |
acceleration | (Sweep Rate = 1 octave/minute) | (Sweep Rate = 1 octave/minute) |
|
|
|
Certifications
Category | Compliance |
EMC | CISPR 22/CISPR 24 (International) |
| FCC, CFR 47 Part 15, Class A (USA) |
| CSA CSO3 Class A (Canada) |
| VCCI Class A (Japan) |
| EN 55022/EN 55024 (with required subtest) (Europe) |
| AS/NZ 3548 (Australia/New Zealand) |
| CNS 13438 (Taiwan) |
| MIC (Korea) |
Safety | IEC 60950 (International) |
| National Deviation per CB Member Countries to IEC 60950 |
| UL 1950, (USA) |
| CSA 22.2, No. 950 (Canada) |
| EN 60950 (Europe) |
| |
| IEC 60950 with deviations (Argentina) |
| IEC 60950 with deviations (Chile) |
|
|
Appendix A: Specifications n31
212779A, December 2001
