Understanding display messages

Messages appear on the Smart Panel program window or on the control panel display to indicate machine status or errors. Refer to the tables below to understand the messages meaning to correct the problem, if necessary.

Note

When you call for service, it is very convenient to provide the service representative with the contents of the display message.



Status display

Explanation

Solution













OPEN

The covers is not

Press the covers until it









completely closed.

clicks.





















There is a problem

Unplug the power cord







LED blinks

in the machine.

and plug it back in. If the









problem persists, contact











the service











representatives.



















LED blinks

There is no paper in

Load paper in the tray.









the tray.

(Page 4.5)





























In the paper feed

Clear the jam. (Page 7.1)









area and rear the









LED blinks

machine.













Rear and Inside the

Clear the jam. (Page 7.3)

















machine.























In the exit area.

Clear the jam. (Page 7.5)





















Small amount of

Take out the









toner is left in the

corresponding toner







LED blinks

cartridge. The

cartridge and thoroughly







estimated

shake it. By doing this,

slowly

cartridge lifea of

you can temporarily









toner is close.

reestablish printing











operations. (Page 8.4)













Status display

Explanation

Solution

















A toner cartridge

Replace the toner







has almost

cartridge for the best







reached its

print quality when this







estimated

message appears.







cartridge life.a

Using a cartridge









beyond this stage can









result in printing quality









issues. (See









"Replacing the toner





LED blinks



cartridge" on page 8.5.)

rapidly





The toner cartridge

Reinstall the toner













is installed

cartridge two or three







improperly, or not

times. If the problem







installed.

persists, the toner









cartridge is not being









detected. Please contact









the service









representatives. (Page









6.5)











T1

The toner cartridge

Install the a Samsung-







which the arrow

genuine toner cartridge







indicates is not

designed for your







suitable for your

machine.







machine.













T2

A toner cartridge

It is recommended to







has almost

replace the toner







reached its

cartridge. (See







"Replacing the toner







estimated







cartridge" on page 8.5.)







cartridge life.a

T3

The toner cartridge

Replace the







which the arrow

corresponding toner







indicates is not a

cartridge with a Samsung-







Samsung-genuine

genuine cartridge.







cartridge.

(Page 6.5)











a.Estimated cartridge life means the expected or estimated toner cartridge life, which indicates the average capacity of print-outs and is designed pursuant to ISO/IEC 19752. (page 9.1) The number of pages may be affected by operating environment, printing interval, media type, and media size. Some amount of toner may remain in the cartridge even when the red LED turned on and the printer stops printing.

Caution

Samsung does not recommend using non-genuine Samsung toner cartridge such as refilled or remanufactured. Samsung cannot guarantee non- genuine Samsung toner cartridge's quality. Service or repair required as a result of using non-genuine Samsung toner cartridges will not be covered under the machine warranty.

7.7 <Troubleshooting>
