Samsung 760TFT manual Microsoft Windows 95 Operating System, Microsoft Windows NT Operating System

7.Click the "Have Disk" button, then click "browse.." button.

8.Specify A:\(D:\driver) then click "OK" button.

9.The "Select Device" dialogue box will appear. Select "Show all devices" then choose the monitor that corresponds to the one you connected to your computer and click OK.

10.Continue choosing "Close" button and "O.K" button until you close the Display Properties dialogue box.

Microsoft® Windows® 95 Operating System

First determine the Windows 95 version installed on your computer by right-clicking the My Computer icon on PC and selecting Properties. The version number is listed under System. Perform the steps for the appropriate version.

Version 4.00.950A

1.Click Start, Settings, Control Panel, and then double-click "Display" icon.

2.In the "Display Properties" window, click the "Settings" tab and click "Change Display Type".

3.In the "Change Display Type" window, click "Change" and then click "Have Disk".

4.Click "browse.." button and specify A:\(D:\driver) and click "OK".

5.In the Select Device window, click the appropriate monitor model and then click OK.

6.Continue choosing "Close" button and "OK" button until you close the "Display Properties" dialogue box.

Version 4.00.950B

1.Click Start, Settings, Control Panel, and then double-click "Display" icon.

2.In the "Display Properties" window, click the Settings tab and then click "Advanced Properties" button.

3.In the "Advanced Display Properties" window, click the "Monitor" tab and then click "Change" button.

4.In the "Select Device" window, click "Have Disk" button.

5.Click "browse.." button and specify A:\(D:\driver) and click "OK".

6.In the "Select Device" window, click the appropriate monitor model and then click "OK".

7.Continue choosing "Close" button and "OK" button until you close the "Display Properties" dialogue box.

Microsoft® Windows® NT Operating System

1.Click Start, Settings, Control Panel, and then double-click Display icon.

2.In Display Registration Information window, click Settings Tab and then click All Display Modes.

3.Select a mode that you wish to use (Resolution, Number of colors and Vertical frequency) and then click OK.

4.Click Apply button if you see the screen working normally after clicking Test. If the screen is not normal, change to a different mode (lower mode of resolution, colors or frequency).

Note: If there is no Mode at All Display Modes, select the level of resolution and vertical frequency by referring to the Preset Display Modes in the user guide.

Linux Operating System

To execute X-Window, you need to make the X86Config file, which is a type of system setting file.

1.Press Enter at the first and the second screen after executing the X86Config file.

2.The third screen is for setting your mouse.

3.Set a mouse for your computer.

4.The next screen is for selecting a keyboard.

5.Set a Keyboard for your computer.

6.The next screen is for setting your monitor.

7.First of all, set a horizontal frequency for your monitor. (You can enter the frequency directly.)

8.Set a vertical frequency for your monitor. (You can enter the frequency directly.)

9.Enter the model name of your monitor. This information will not affect the actual execution of X-Window.

10.You have finished setting up your monitor.

Execute X-Window after setting other requested hardware.
