Page 37

User’s Manual

On-Screen Display

Menu

How to adjust









Brightness

Adjust the Brightness.

1.Push the Menu ( ) button.

2.Push the Menu ( ) button to open the Brightness adjustment screen.

3.Use the + button to increase the brightness or - button to decrease the brightness.

Direct Access Feature :

When OSD is not on the screen, Push the + or - button to adjust brightness.

Contrast

Adjust the Contrast.

1.Push the Menu ( ) button.

2.Push the - button or + button until the Contrast screen is displayed.

3.Push the Menu ( ) button to open the Contrast adjustment screen.

4.Use the + button to increase the contrast or - button to decrease the contrast.
