HOW TO USE THE REMOTE

TO CONTROL YOUR PLASMA TV

mAV NET button

Press this button to access the Audio/Video network (AV Net) menu. The AV Net allows the user to control external components with the Plasma TV’s remote control. When you press the AV NET button, the following window will pop up within the Display Monitor screen. The window will disappear after 30 seconds if you don’t press any buttons.

Select Device Setup to start.

Use CURSOR PAD G, H, F, E to navigate and SELECT to select button. The command on the button is passed through the IR mouse and onto the AUDIO/VIDEO equipment. These on-screen buttons are called “Soft Keys”.

Customize your Audio/Video equipment list and soft keys by selecting the Custom options and following the instructions of the AV NET learning wizard (see page 32).

This window shows the available Audio/Video equipment soft keys. The equipment list will scroll up or down.

DVD	POWER MENU MORE
DVD2	ORIGINAL MENU
VCR	OF EQUIPMENT
VCR2
AV Receiver	MORE..
Move SEL Select	Move AV NET Return
	2x

DVD	POWER	CH H	CH G	MENU
DVD2				TV/VCR	ORIGINAL MENU
VCR			P	MORE	OF EQUIPMENT
VCR2
AV Receiver					MORE..

Move	SEL Select	Move	AV NET Return
		2x

THE REMOTE

DVD	POWER	CH H	CH G
DVD2	AUDIO	VOL H	VOL G
VCR	Inputs:
VCR2	SOURCE1	SOURCE2	SOURCE3	SOURCE4
AV Receiver	SOURCE5	SOURCE6	SOURCE7	SOURCE8

Move SEL Select

PV Recorder	POWER	CH H	CH G	MENU
Cable Box				TV/VCR
Set Top Box				INFO
Custom				GUIDE
Device Setup				MORE

Move SEL Select

PV Recorder			POWER	CH H	CH G	INFO
Cable Box			1	2	3
Set Top Box			4	5	6
Custom			7	8	9
Device Setup			LAST CH	0
Move	SEL	Select

PV Recorder	POWER	CH H	CH G	MENU
Cable box	1	2	3	INFO
Set Top Box	4	5	6	GUIDE
Custom	7	8	9
Device Setup	LAST CH	0

Move SEL Select

MORE..

ORIGINAL MENU

OF EQUIPMENT

Move AV NET Return

PV Recorder

Cable box

Set Top Box

Custom

Device Setup

Move SEL Select

CONTROL

NOTES: 1. Devices will not be available until Device Setup is completed (see pages 22-24).

2.The “Custom” option will not be available until the Custom device Setup is learned and completed. After completion, the “Custom” tag will be replaced with the device tag (see page 32).

3.The Custom option only accepts one device at a time. The second Custom device setup will replace the first device.
