07Initial Settings menu

Chapter 7

Initial Settings menu

Using the Initial Settings menu

The Initial Settings menu provides audio and video output settings, parental lock settings, and display settings, among others.

If an option is grayed out it means that it cannot be changed at the current time. This is usually because a disc is playing. Stop the disc, then change the setting.

1Press HOME MENU and select ‘Initial Settings’.

Initial Settings

2Use the cursor buttons and ENTER to select the setting and option you want to set.

All the settings and options are explained on the following pages.

Note

•In the table below, the default setting is shown in bold: other settings are shown in italics.

•The Digital Audio Out settings only need to be set if you have connected the digital output of this player to an AV receiver, or other equipment.

•Check the operating instructions supplied with your other equipment to see which digital audio formats it’s compatible with.

•Some settings, such as TV Screen, Audio Language and Subtitle Language may be overridden by the DVD disc. Often these settings can also be made from the DVD disc menu.

Digital Audio Out settings

Setting	Option	What it means
Digital Out	On	Digital audio is output from the digital outputs.
	Off	No digital audio output.
Dolby Digital Out	Dolby Digital	Dolby Digital encoded digital audio is output when playing a
		Dolby Digital DVD disc.
	Dolby Digital > PCM	Dolby Digital audio is converted to PCM audio before being
		output.
DTS Out	DTS	DTS encoded digital audio is output when playing a DTS disc.
		(Noise will be output if your amplifier/receiver is not compatible
		with DTS audio.)
	Off	No digital audio is output when playing a DTS disc.
96 kHz PCM Out	96kHz > 48kHz	96kHz digital audio is converted to 48kHz for digital output.
	96kHz	96kHz digital audio is output as is at 96kHz.
