Page 6

Disc Types (Logos)

Recording Types

Disc Size

Max. Playing Time

Characteristics











DVD

Audio

12 Cm

Single-sided 240 min.

• DVD contains excellent sound and video



Double-sided 480 min.

due to Dolby Digital and MPEG-2 system.



+



• Various screen and audio functions can





Single-sided 80 min.



Video

8 Cm

be easily selected through the on-screen



Double-sided 160 min.







menu.



















AUDIO-CD



12 Cm

74 min.

• An LP is recorded as an analog signal



Audio

with more distortion. CD is recorded as a







Digital Signal with better audio quality,





8 Cm

20 min.

less distortion and less deterioration of





audio quality over time.



















* It may not be to play CD-R,CD-RW and DVD-R in all cases due to the type of disc or condition of the recording.

Unpack

When you unpack the DVD-VCR, please check the following list of items is included in the packing case.

DVD-VCR

RF Antenna Cable

User’s Guide

RCA cable for

Audio/Video connection

Remote Control

EP-2 Plug Converter

1.5V “AAA” Batteries- 2EA

ENG-5
