Samsung LN32B530, LN46B530, LN52B530, LN40B530, LN37B530 user manual Operation, Viewing the menus

Page 23

Operation

¦Viewing the menus

Before using the TV, follow the steps below to learn how to navigate the menu in order to select and adjust different functions.

1.Press the MENU button.

The main menu is displayed on the screen. Its left side has the following icons: Picture,

Sound, Channel, Setup, Input, Application, Support.

2.Press the ▲ or ▼ button to select one of the icons. Press the ◄ or ► button to access the icon’s sub-menu.

3.Press the ▲ or ▼ button to move to items in the menu.

Press the ENTEREbutton to enter items in the menu.

4.Press the ▲/▼/◄/► button to change the selected items.

N Press the RETURN button to return to the previous menu.

5.Press the EXIT button to exit from the menu.

Using the remote control buttons


Mode

: Standard

Backlight

: 8

Contrast

: 95

Brightness

: 45

Sharpness

: 50

Color

: 50

Tint (G/R)

: G50/R50

Button

Operations

MENU m

Display the main on-screen menu.

RETURN R

Return to the previous menu.

EXIT e

Exit the on-screen menu.

Button

Operations

▲/▼/◄/►/

Move the cursor and select an item.

ENTERE

Select the currently selected item.



Confirm the setting.





Example: Setting the TV’s Brightness in the Picture Menu

Adjusting the Brightness to 80

1.Press the MENU button to display the menuConnecting.a PC

2.Press the ENTEREbutton to select Picture.

3.Press the ▲ or ▼ button to select Brightness.

4.Press the ENTEREbutton.

5.Press the ◄ or ► button until the Brightness changes to 80.

6.Press the ENTEREbutton.

N Press the EXIT button to exit from the menu.


Mode







: Standard















Backlight







: 8













Contrast







: 95











Brightness

: 45











Sharpness

: 50











Color







: 50











Tint (G/R)







: G50/R50






Mode







: Standard











Backlight







: 8













Contrast







: 95











Brightness

: 45











Sharpness

: 50











Color







: 50











Tint (G/R)







: G50/R50







Backlight







: 8












Contrast







: 95









Brightness

: 45













Sharpness

: 50











Color







: 50











Tint (G/R)







: G50/R50







Advanced Settings















Picture Option















Picture Reset







































Brightness

















45





























UMove

LAdjust

EEnter

RReturn



Brightness

















80





UMove

LAdjust

EEnter

RReturn

English - 21
