Hitachi 57F510 important safety instructions Timers, On-Screen Display, Set The Clock

Page 52
TIMERS

TIMERS

Timers

Select Timers to set your Clock, Sleep Timer, Event Timer and Day/Night Timer Recordings.

Timers Video

Set The Clock Audio

Manual backgroundManual background Aspect

Manual background Chan. Manager

Manual background Locks

Manual background Timers

Manual background Setup

Move SEL Sel

Manual background Timers

Manual background Set The Clock

Manual backgroundSet Sleep Timer

Manual background Set Day/Night Timer Manual background Set Event Timer

Move

Select

SEL Return

Set The Clock

The Clock must be adjusted before you can use the “Set Event Timer” or Day/Night Timer” feature.

Manual background Timers

Manual backgroundSet The Clock

Manual backgroundSet Sleep Timer Manual background Set Day/Night Timer

Manual background Set Event Timer

Timers





Set The Clock

Time:



2:53 PM Jun 28 2004

Move

SEL

Return

Use the CURSOR buttons to highlight the current time (hour and minute), AM or PM, Month, Day, and Year. Use the CURSOR buttons , to adjust settings.

Press the SELECT button to set the Time and Date. Press EXIT to quit the menu.

NOTES: When “Daylight Saving Correction” is checked “”, the TV will automatically calculate the clock adjustment for Daylight Saving.

ON-SCREEN DISPLAY

52
