Philips manual 14PT1582 20PT1582 21PT1582, TV System Versions, Specifications

Page 22

SPECIFICATIONS





2 2

























14PT1582

20PT1582

21PT1582













Picture tube size

37 cm

51 cm

54 cm











Picture tube visible area

34 cm

48 cm

51 cm











Audio Output

1 x 3 W

2 x 2 W

2 x 2 W













Set dimensions











Width

36 cm

50 cm

52 cm

Height

36 cm

46 cm

47 cm

Depth

37 cm

47 cm

48 cm

Nett weight of set

11 kg

18 kg

20 kg

TV System

Versions

57

59

73

75

PAL B/G

x

x

PAL D/K

x

x

PAL I

x

x

SECAM B/G

x

SECAM D/K

x

SECAM K1

x

NTSC Playback

x

x

x

x

PAL 60 Playback

x

x

x

x

Note

For Operating Voltage, Frequency, Power Consumption and Version Number, refer to the type sticker at the rear of the set.
