Philips 20PT1582, 21PT1582, 14PT1582 manual Functions of TV Front CONTROLS/SOCKETS

Page 4

FUNCTIONS OF TV FRONT CONTROLS/SOCKETS

4

1

2

3

INSTALL /

MENU

n	ý	ú	ü û	14PT1582
VIDEO	AUDIO		ü CHANNEL û	14PT1582
	L VOLUME K		ü CHANNEL û
				20PT1582
4	5	6	7

3

INSTALL /

MENU

ý úü û


L VOLUME K		üCHANNEL û

1

2

3

n	VIDEO	AUDIO

4 5

21PT1582

6 7

1. Mains Power button

Switch mains power on or off.

2.Standby light indicator Indicate red light when standby mode is activated.

3.	Remote Sensor	Aim remote control handset at remote sensor when
		operating the TV.
4.	Headphone socket	Connect headphone jack to socket for personal listening.
5.	AV “in” sockets	Connect to Video “out” and Audio “out” sockets of VCR
		laser disc player, etc.

6.Volume ý / ú button Adjust sound volume louder/softer.

7.Channel ü / û button Select channel in ascending/descending order.

Note : You can enter the main menu by pressing both the Volume ý / ú buttons at the same time.

Press Channel ü / û button to select items on the menu.

Press Volume ý / ú button to activate sub-menu.
