Maxi-Cosi Priori manual Rear-Facing Installation with Latch, Twist belt

Page 16
5
NOTE: Locking clip is shown installed.

4358-4274 US Priori 5/25/07 8:33 AM Page 31

4

Push down firmly

on the child restraint



and pull up on belt



to tighten. For a



manual belt, refer to



“Knowing your



Vehicle Belt”



section. Pull up on

Rear-Facing Installation with LATCH

NOTE: Do not use the LATCH system along with the adult lap or lap/shoulder belt.

Rear Facing Use:

shoulder strap to

remove any slack.

With weakest hand at belt path, tilt and

push the child

restraint forward

and back, and from side to side. If the seat belts do not loosen, your child

restraint should be

secure.

NOTE: Some “play” from front to back or about an inch from side to side is

acceptable. If it moves more, review “Knowing your Vehicle Belts” and “The Locking Clip” sections.

6

After checking for

hot seat and



buckles, secure



child as described



in “Securing Your



Child in the Child

1

2

To thread the LATCH belt, put belt end with connector and adjuster through the rear-facing belt path slot.

Thread UNDER seat pad behind the crotch strap and out opposite side.

Do not place vehicle belt over child’s legs.

5-35 lbs. (2.3-16 kg), 19-36” (48-91 cm)

Restraint” section.

!WARNING

Using this child restraint in any vehicle seat where the lap belt cannot be tightened securely and properly or where it can be loosened by pulling on it can result in serious injury or death.

3

Adjuster MUST be

on the left side of





child restraint as



shown. DO NOT



twist belt.

28

29 continued on next page.
