Panasonic SDR-H50 Setup 4 Adjusting LCD monitor, Setup # LCD SET # YES, Brightness, Colour

Page 28

Setup 4 Adjusting LCD monitor

≥These settings will not affect the images actually recorded.

Adjusting the brightness and colour level

1 Select the menu. (l 24)

[SETUP] # [LCD SET] # [YES]

2 Select the item and then adjust the settings with the joystick.

[BRIGHTNESS]:

Brightness of the LCD monitor

[COLOUR]:

Colour level of the LCD monitor

Increasing and decreasing the brightness of the entire LCD monitor

Press the POWER LCD PLUS button.

POWER

LCD PLUS

Each time you press the button:

1Original brightness

2 Bright

3 Brighter

4 Darker

5 Dark

1
	5	-1
2	+1
	4	-2

≥ If you turn on the unit when the AC adaptor is used, this function will automatically be “Bright”.

LSQT1346
