Operation

Turning the Inverter On and Off

Turning the Inverter Off Between Charges

The power switch on the inverter’s front panel turns the control circuit in the PROwatt SW Inverter on and off.

To toggle the inverter on and off from its front panel:

1.Press the inverter’s power switch button (for half a second) to turn On the inverter (from Off).

2.Press the inverter’s power switch button (for one second) to turn Off the inverter (from On).

Note: When the inverter’s power switch button is Off, the inverter draws no current from the battery.

WARNING: Risk of electrical shock.

The unit’s power switch when turned off does not disconnect power from the PROwatt SW Inverter.

Operating Several Loads at Once

If you are going to operate several loads from the PROwatt SW Inverter, turn them on separately after you have turned the inverter on.

This will ensure that the inverter does not have to deliver the starting current for all the loads at once.

When the power switch is on but no power is being supplied to a load, the inverter draws less than 800 mA from the battery. This is a low current draw. It would take a week to discharge a 150 Ah battery at this current, so you don’t have to worry about excessive drain on your battery if you leave the inverter switched on for a few days.

If you are not planning to recharge your battery within a week or so, switch the inverter off.

GFCI-Protected AC Outlets

The AC outlets are Ground Fault Circuit Interrupter (GFCI) outlets. This protects you against hazardous electrical shocks that could be caused by dampness, faulty mechanism in the appliance, worn insulation, etc. GFCI-protected outlets cut off hazardous electrical shocks quickly enough so an adult in normal health is not seriously injured (infants and small children may still be affected).

Important: Test the GFCI periodically to make sure it is operating correctly.

975-0529-01-01

15
