Overview

Fp

The oe7??A: is a high performance balanced stereo audio DA (distribution amplifier) using XLR connectors that includes:

￿Front panel output level trimmer controls

￿Active J-FET amplifying circuitry that ensures hum-free, full- bandwidth operation

￿A high-power discrete buffering system providing excellent performance

You can configure your oe7??A: as a mono DA (2x1:10 or 1:20) or as a stereo DA (2x1:5 or 1:10).

Achieving the best performance means:

￿Connecting only good quality connection cables, thus avoiding interference, deterioration in signal quality due to poor matching, and elevated noise levels (often associated with low quality cables)

￿Avoiding interference from neighboring electrical appliances that may adversely influence signal quality

￿Positioning your Kramer oe7??A: in a location free from moisture and away from excessive sunlight and dust

G b u a d

Figure 1 illustrates the front and rear panels of the oe7??A:. Table 1 and

Table 2 define the front and rear panels of the oe7??A:, respectively.
