Frigidaire Electric Patio Grill manual Trouble Shooting, Before calling customer service

Page 22

Trouble Shooting

General Trouble Shooting

You should inspect the burners at least once a year or immediately if any of the following conditions occur: The smell of gas in conjunction with the burner flames appearing yellow.

The Grill does not reach temperature. The burners make a popping noise. The Grill heats unevenly.

Before calling customer service

If the Grill does not function properly, use the following checklist.

Problem





Solution







After opening tank valve, be sure one of the







Grill control knobs is on high for at least 4







seconds while pushing ignitor button.







Check tank fuel level.

Grill will not light when the ignitor button is pushed.





Check for loose wire connections.













Remove the cooking grates and flavor grids.







Push ignitor button, and check for spark on tip







of electrode.







Check to see if debris is blocking the







electrode sparks.







Check battery/replace battery.







Attempt to match light the burner.







If using L.P. gas, disconnect gas line at tank,







then reconnect.















Check for proper gas supply and pressure.

Low heat with knob in “High” position.





If using L.P. gas check for low fuel level.













If using L.P. gas check for kinks in supply line.







If only one burner appears low, clear burner







ports of any obstructions.







Pre-heat Grill for a full 10 minutes.







If using L.P. gas, disconnect gas line at tank,







then reconnect.











21





Image 22
Contents Grill Assembly Built-In Instructions5-12 13-15 16-19 21-22 Welcome & Congratulations Please Carefully Read and Save These InstructionsGeneral Safety Instructions Important Safety InformationGrill Features FD30 Grill Components List Cart PartsGrill Assembly Cart Assembly, Door Stops & Door Pivot BoltsAttaching Grill Head to Cart Installing the Cart Door Handles Installing the Drip TrayInterior parts installation Side Shelf AttachmentSide Burner Assembly Side Burner Parts Assembly Built-In Instructions Required Ignitor cutout for front or side mount Gas Requirements Natural Gas InstallationGeneral Information Gas Installation Tank InformationBefore Testing Leak TestingTesting Using the Grill Grill LocationBefore Lighting Lighting the GrillMatch Lighting Remove warming shelf when using rotis Using the Rotisserie & Side BurnersAttaching the Rotisserie purchased separately Rotisserie Lighting Side Burner LightingCare and Maintenance Before calling customer service Trouble ShootingProblem Solution Spider and Insect Warning Warranty Limited Lifetime Warranty
