Grill Features: FD30
1 | 7 |
| 8 |
2
| 9 |
3 | 13 |
| |
| 14 |
4 |
|
| 10 |
5 | 12 |
| |
6 | 11 |
|
1. | Roll top grill hood | 8. | Warming shelf |
2. | Grilling/Cooking surface | 9. | Infrared back burner |
3. | Side Shelf | 10. | Electronic ignitor: main, rear infrared |
|
|
| & side burner |
4. | Control knob: back infrared burner | 11. | Cart w/doorr |
5. | Control knobs: main burners | 12. | Ignitor access opening |
6. | Convection vents | 13. | Side Burner |
7. | Handle | 14. | Control knob: Side Burner |
|
|
|
|
|
