Connecting the base station to a PABX

Press keys:

Connecting the base station to a PABX

Dialling mode and flash time

Step 1: Changing the dialling mode

It is necessary to change the dialling mode only if your PABX does not operate with the preset tone dialling (DTMF - dual-tone multifrequency. Please refer to the operating instructions of your PABX.

Options:

– Tone dialling (DTMF),

– Dial pulsing (DP). OOOOOOOOOOOO0(18 Open the menu.

OOOOOOO OOOOOOOOOOOOOOOOOOOOOOOOOOOOOOOO%$6(6(7 OOOOOOO Select the menu item and confirm. OOOOOOO OOOOOOOOOOOOOOOOOOOOOOOOOOOOOOOO$'')($785(6 OOOOOOO Select the menu item and confirm.

OOOOOOOOOOOOOOOOOOOOOOOOOOOOOOOO',$/02'( OOOOOOO Confirm.

OOOOOOO OOOOOOO Select the required dialling mode and confirm.

Step 2: Setting the flash time:

Prerequisite:

Your PABX requires a flash time different to the preset flash time, Please refer to the operating instruc- tions of your PABX.

OOOOOOOOOOOO0(18 Open the menu.

OOOOOOO OOOOOOOOOOOOOOOOOOOOOOOOOOOOOOOO%$6(6(7 OOOOOOO Select the menu item and confirm. OOOOOOO OOOOOOOOOOOOOOOOOOOOOOOOOOOOOOOO$'')($785(6 OOOOOOO Select the menu item and confirm.

OOOOOOO OOOOOOOOOOOOOOOOOOOOOOOOOOOOOOOO7%5OOOOOOO Select the menu item and confirm. OOOOOOO OOOOOOO Select the flash time and confirm.

80 ms, 100 ms, 120 ms, 180 ms, 250 ms, 300 ms, 600 ms.

¬ The current setting is marked with '.

41

Image 45
