Connector Pin Assignments

Table A-6

Serial

Pin

Signal

Pin

Signal









1

Carrier detect

6

Data set ready









2

Receive data

7

Ready to send









3

Transmit data

8

Clear to send









4

Data terminal ready

9

Ring indicator









5

Ground













A–4

Maintenance and Service Guide
