Verifying that SNA Link is properly installed and configured prior to this installation of SNA DHCF/iX unless SNA Link will be installed at the same time.

Updating the HP 3000 system to the proper release level and installing the SNA DHCF/iX software using AUTOINST. Refer to the HP 3000 MPE/iX Installation and Update Manual (36123-90001).

Verifying that all of the necessary software modules have been successfully installed by AUTOINST and are at the correct version levels using the NMMAINT.PUB.SYS utility.

Performing full system backups as neces- sary and ensuring that the HP 3000 system and personnel with HP 3000 system man- agement knowledge are available when HP is onsite to complete the minimum configu- ration of SNA DHCF/iX.

The customer is also responsible for completing the configuration in order to fully integrate SNA DHCF/iX into the existing customer network after HP has completed the minimum configuration of SNA DHCF/iX.

HP Responsibility

Following the installation of SNA DHCF/iX, HP is responsible for the following:

Confirming that all of the necessary soft- ware modules have been installed and are at the correct version level.

Configuring the SNA DHCF/iX product to a minimum configuration (1 LU) in order to verify software and hardware functionality.

Verifying the SNA DHCF/iX configuration by issuing the DHCFCONTROL START com- mand and ensuring that the LU to SSCP session becomes active for the LU that was configured.

These steps complete HP’s portion of the installation and minimum configuration of SNA DHCF/iX.

Additional Implementation

Assistance

For implementation needs that go beyond installation, the customer can either provide self-support or can purchase additional services from HP. These services include Network Startup and HP ConsultLine. In addition, the customer can also purchase service from HP on a time-and-materials basis.

Network Startup includes implementation scheduling and coordination assistance, network configuration and verification testing, and network documentation.

Ordering Information

Product/Option



Number

Description

A5563A

SNA Link Interface Card

010

RS-232-C Synchronous



Modem Connection

020

V35 Synchronous



Modem Connection

025

Autodial Connection

0D1

Factory Integration

Required for SNA/SDLC, SNA/Services bundle, NS Point-to-Point, RJE, BSC/iX Softwares (option 001 CIB/CIO become obsolete)

Product/Option



Number

Description

30292B

SNA Services License,



Software and Documentation

310

Tier 1 License (also applies to 315,



320 Tier 2, 3 systems)

330

Tier 4 License (also applies to 335



Tier 5 systems)

340

Tier 6 License (also applies to 350



Tier 7 systems)

0CD

Upgrade credit Tier 1

0CF

Upgrade credit Tier 4

Requires A5563A.



Includes former 30202A, 30293A, 30294A, and 36935A.

Customers must also order the MPE media product (51543B) on MPE/iX 5.5 Express 7 or later, or MPE/iX 6.0 Express 1 or later. This is required to receive software for this product.
