EXIT

The EXIT menu is used to quit the CAMERA SET menu of the SCC-C6403P and return to the MAIN MENU.

- QUIT

: Ignores the changed information and restores the saved



information.

- SAVE

: Saves the information of the setting condition of the menu.

-PRESET : Ignores the changed information and restores the initial factory defaults of the menu.

For items in the BLC menu, the user can set the size and location of the BLC area by pressing [ENTER] key after put the cursor on USER… using the [Left, Right] key. For SIZE items, you can use the [Up, Down, Left, Right] key to designate the SIZE, and then press the [ENTER] key.

You can set the location for areas using the [Up, Down, Left, Right] key in the LOCATION.

2. VIDEO SET MENU

IRIS

There is a function to automatically adjust IRIS to the incoming light level. Owing to this function, you may set up the brightness level yourself.

The ALC(Auto Light Control) menu allows you for video output level setup.

ALC

Choose the ALC of the IRIS item and press [ENTER] and set he submenu to the Video Output level and BLC will be shown.The Video Output Level can be set in the level item using the [Left, Right] keys.

BLC (Submenu of the ALC menu)

If you use a general camera to photograph a subject under backlight or bright illumination, the subject will be shown dark on the monitor due to the backlight. BLC(Back Light Compensation) is used to prevent such a backlight problem to secure distinct images under bright illumination.

(ALC)





BLC









USER...





LEVEL

(0) ----I----





RET

































































































SIZE

































































































LOKALIZACJA

Press [Enter]

Press [Enter]

SIZE

LOKALIZACJA

SIZE

LOKALIZACJA

E

Using the [Left, Right] keys, you can set up BOTTOM…, TOP…, LEFT…, RIGHT…, CENTER… 5 preset areas and the USER…function that can directly set the areas. For example, for the items in the BLC menu, you can confirm the preset BOTTOM area by pressing [ENTER] key in the BOTTOM… status.

Use [Left, Right] key in the LEVEL menu to control the video output level(brightness).





(VIDEO SET)





















ALC...







IRIS







SHUTTER

AUTO X2...







MOTION

NORM







WHITE BAL

ATW1







DIS

---







FOCUS MODE

ONEAF







SPECIAL

...







EXIT

QUIT



























Press [Enter]

(ALC)

BLCOFF

LEVEL (0)----I----

RET

MANU

When you press [ENTER] key after selecting MANU in the IRIS item, an additional screen appears in which you can set manually opening or closing the IRIS.

(ALC)

BLC



BOTTOM...

LEVEL

(0)----I----

RET



Press [Enter]



(VIDEO SET)

























IRIS



MANU...







SHUTTER

OFF







AGC

OFF







WHITE BAL

ATW1







DIS

OFF







FOCUS MODE

ONEAF







SPECIAL

...







EXIT

QUIT



























Press [Enter]

(MANUAL)

LEVEL

(00) ----I----

RET



3-10

3-11

Image 18
