FOCUS MODE

In the FOCUS MODE MENU, the Focus method can be set to ONEAF (One Auto Focus), or MF(Manual Focus).

-ONEAF : In the ONEAF mode, it automatically sets the focus after the PAN/TILT/ZOOM moves, and operates as the same in the MF mode if the



PAN/TILT/ZOOM does not move.

- MF

: In MANUAL FOCUS MODE the user adjusts the Focus manually.



Use the left/right keys to select ONEAF orMF in the FOCUS MODE menu.















(VIDEO SET)









IRIS

ALC...





SHUTTER

OFF





AGC

OFF

EXIT

It's the same as the EXIT function of the CAMERA SET menu.

3. PRESET

This is the menu that user sets the PAN/TILT location, Zoom/Focus, and screen condition, so the camera can monitor the presetting area on demand. A total of 128 presets are available.

E

WHITE BAL

ATW1

DIS

OFF

FOCUS MODE



ONEAF

SPECIAL

...

EXIT

QUIT

ONEAF can only be selected if SHUTTER is set to OFF, 1/100(1/120) ~1/10K, or AUTOX2...

In other modes (AUTOX4...~AUTOX128...), FOCUS mode will be displayed as “MF“(the product automatically switches into MF mode).You can ’t adjust the settings manually.

ONEAF function may not possible withe types of objects listed below. For such objects, focus manually.

-High intensity objects or objects illuminated with low lighting

-Obejects shot through wet or dirty glass

-Pictures that are a mixture of distant and nearby objects

-White alls and other single-color objects

-Venetian blinds and other horizontally striped objects

SPECIAL

In SPECIAL menu, you can directly adjust Y-LEVEL, C-LEVEL, and DETAIL

functions.



- Y-LEVEL

: It is used to set the levels for the Sync signal and the entire



brightness signal of the video signal.

- C-LEVEL

: It is used to set the levels for the Burst signal and the entire colour



signal of the video signal.

- DETAIL

: Controls both horizontal and vertical distinction.

** MAIN MENU **

CAMERA SET...

VIDEO SET...

PRESET ...

ZONE SET...

AUTO SET...

ALARM SET...

OTHER SET...

SYSTEM INFO...





(PRESET MAP)

























0



1

2

3

4

5



6

7

8

9







10



11

12

13

14

Press

15



16

17

18

19

[Enter]

20



21

22

23

24

25



26

27

28

29







30



31

î ï RET





ID:PRESET 0





































PRESET NO.0















POSITION SET



...



PRESET ID



ON...

Press



VIDEO SET



OFF



PRESET SPEED

8

[Enter]





DWELL TIME



3S





IMAGE HOLD



OFF



EXIT







QUIT







































(VIDEO SET)













IRIS

ALC...





SHUTTER

OFF





AGC

ON





WHITE BAL

ATW1





DIS

ON





FOCUS MODE

ONEAF





SPECIAL



...





EXIT

QUIT























Press [Enter]





(SPECIAL)



























Y-LEVEL



(0)I--------







C-LEVEL

(0)I--------







DETAIL

(0)--I-







RET





























3-16

3-17
