Samsung DVD-SH873M/XEU manual Disc Format, Copy Protection

Page 7

COPY PROTECTION

•Many DVD discs are encoded with copy protection.

•This product incorporates copyright protection technology that is protected by methods claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorised by Macrovision Corporation, is intended for home and other limited viewing uses only unless otherwise authorised by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Protection

This HDD & DVD Recorder can allow you to protect the contents of your discs, as described below.

•Programme-protected : See page 85 “Locking (Protecting) a Title”

•Disc-protected : See page 100 “Disc Protection”

❋DVD-RAM/±RW/±R discs that are incompatible with the DVD-VIDEO format cannot be played with this product.

❋For more information on DVD recording compatibility, consult your DVD-RAM/±RW/±R manufacturer.

❋Use of poor quality DVD-RAM/±RW/±R discs may cause following unexpected problems including, without limitation, recording failure, loss of recorded or edited materials or damage to the HDD & DVD Recorder.

Disc Format

❖Using MP3 disc

•CD-R/-RW, DVD-RAM/±RW/±R, HDD, USB with MP3 fi les recorded with UDF, ISO9660 or JOLIET format can be playbacked.

•Only MP3 fi les with the “.mp3” or “.MP3” extension can be played.

•For MP3 fi les recorded with a VBR(Variable Bit Rates), from 32 Kbps to 320 Kbps, the sound may cut in out.

•Playable bit-rate range is from 56 Kbps to 320 Kbps.

•Each folder can have up to 500 items including fi les and sub folders.

❖Using JPEG disc

•CD-R/-RW, DVD-RAM/±RW/±R, HDD, USB recorded with UDF, ISO9660 or JOLIET format can be playbacked.

•Only JPEG fi les with the “.jpg” or “.JPG” extension can be displayed.

•Each folder can have up to 500 items including fi les and sub folders.

•MOTION JPEG and progressive JPEG are not supported.

❖Using DivX disc

•Disc : CD-R/-RW, DVD-RAM/±RW/±R, HDD, USB

•Video File with following extensions can be played. : .avi, .divx, .AVI, .DIVX

•DivX Video (Codec) Format : DivX 3.11, DivX 4.x, DivX 5.x (without QPEL and GMC)

•DivX Audio (Codec) Format : MP3, MPEG1 Audio Layer 2, LPCM, AC3, DTS

•Supported subtitle fi le formats: .smi, .srt, .sub, .psb, .txt, .ass

•Each folder can have up to 500 items including fi les and sub folders.

•You cannot play back the disc that is larger than a 720 x 576 pixel resolution.

● GETTING STARTED

English _7
